LANDYINDUS Hydraulic Angle Rotary Broom Skid Steer Attachment – 72"/83"/99" Nylon Brush Manual Tilt

Keep job sites, parking lots, farm lanes, and construction areas clean with the LANDY S-AB Skid Steer Hydraulic Angle Rotary Broom. Available in three working widths — 72" (1830mm), 83" (2110mm), and 99" (2510mm) — this heavy-duty sweeping attachment efficiently clears dirt, debris, gravel, light snow, and loose material from paved surfaces, gravel lots, concrete floors, and compacted earth lanes.

Key Features

• Nylon Brush Elements: 38 / 44 / 53 brushes (by model) for effective sweeping on asphalt, painted concrete, and finished surfaces without abrasion risk — replacement brushes available on request
• 30° Manual Tilt Angle: Direct swept material to either side for windrow collection, edge clearing, or directional debris management — no additional hydraulic circuit required
• Hydraulic Brush Drum Drive: Consistent rotation speed at 16 MPa / 60 LPM, compatible with standard skid steer auxiliary hydraulic circuits
• 550mm Brush Diameter: Stable, consistent brush contact across the full sweeping width on uneven surfaces
• Universal Quick Attach Mount: MP1140 quick tach system — mounts and dismounts without tools on most skid steer loaders and tractor loaders
• Heavy-Duty Construction: 281–317 kg structural mass ensures stable brush pressure across all three width options

Available Models

• 72" — S-AB1830(72IN)-MP1140: SW 1830mm | 2157×1167×595mm | 38 brushes | 281 kg
• 83" — S-AB2110(83IN)-MP1140: SW 2110mm | 2427×1167×595mm | 44 brushes | 297 kg
• 99" — S-AB2510(99IN)-MP1140: SW 2510mm | 2827×1167×595mm | 53 brushes | 317 kg

Technical Specifications

• Brush Diameter: 550 mm
• Tilt Angle: 30° (manual)
• Operating Pressure: 16 MPa
• Hydraulic Flow: 60 LPM
• Mount Type: MP1140 Universal Skid Steer Quick Attach

Ideal For

• Commercial parking lot & road maintenance
• Construction site clearing & cleanup
• Farm lane sweeping after harvest
• Warehouse, yard & facility surface maintenance
• Edge clearing along walls, curbs & driveways

Technical Drawing:

Contact LANDYINDUS for volume pricing, replacement brush orders, OEM inquiries, or compatibility checks with your skid steer model.
