LANDYINDUS Hydraulic Bale Lifter Handler Skid Steer – Round & Square Bale Roller Tube Quick Attach

Handle round and square bales — including wrapped silage bales — without puncturing the plastic wrap. The LANDYINDUS S-HSBH Skid Steer Hydraulic Bale Lifter Handler features steel roller tubes that cradle bales from beneath, distributing lifting pressure evenly across the full contact area and eliminating the concentrated stress points that cause wrap damage with conventional bale spears or grabs.

Hydraulic arms open from 450mm to 1800mm — the widest opening range in its class — handling everything from small square bales to the largest round bales without manual adjustment or attachment swaps between jobs.

Key Features

• Steel Roller Tube Design: Rolls smoothly under the bale surface, protecting silage plastic wrap completely throughout every lift, carry, and stack cycle — no punctures, no feed spoilage
• 450–1800mm Hydraulic Opening Range: Widest in class — handles small square bales to the largest round bales with no manual adjustment
• Quick-Release Roller Tubes: Tool-free removal when switching to straw or dry hay bale handling where wrap protection is not required — one attachment, multiple bale types
• 1000kg Safe Working Load: Engineered for daily commercial bale handling on dairy farms, beef operations, silage contractors, and large-scale hay producers
• Smooth Hydraulic Arm Control: 16 MPa / 60 LPM — precise positioning in tight barn spaces and accurate stacking at height
• Universal Quick Attach (MP1140): Fast, tool-free mounting to standard skid steer loaders

Technical Specifications

• Model: S-HSBH(1300×850-1200)-MP1140
• Safe Working Load: 1000 kg
• Overall Dimensions (W×D×H): 1320 × 830 × 1440 mm
• Opening Range: 450–1800 mm
• Operating Pressure: 16 MPa
• Hydraulic Flow: 60 LPM
• Weight: 175 kg
• Mount Type: MP1140 Universal Skid Steer Quick Attach

Ideal For

• Silage wrapped bale handling — wrap-safe, zero puncture risk
• Dairy farms & beef feedlot bale management
• Hay contractors handling mixed round & square bale types
• Barn stacking & tight-space bale positioning

Technical Drawing:

Contact LANDYINDUS for volume pricing, OEM inquiries, or compatibility checks with your skid steer model.
