LANDYINDUS 106" Wheel Loader General Purpose Bucket | 2,700mm | 2.24m³ | Straight Edge | 8mm Plate | Big BM Quick Attach | T-LSB2700

LANDYINDUS T-LSB2700-BIG BM 106" Wheel Loader General Purpose Bucket | 2,700mm | 2.24m³ | Straight Edge Cutting Lip | 8mm Main Plate | 1,229kg | Big BM Quick Attach | Mid-Size to Large Wheel Loaders

The LANDYINDUS T-LSB2700 Wheel Loader General Purpose Bucket is a heavy-duty straight edge loader bucket engineered for mid-size to large wheel loaders running Big BM quick-attach coupler systems. At 106 inches (2,700mm) wide with a bucket capacity of 2.24 cubic meters and an 8mm main plate, it is built for high-volume bulk material handling across construction, earthmoving, agriculture, and industrial site applications.

Straight Edge Cutting Lip — Clean Efficient Scooping, No Ground Disturbance, Surface-Sensitive and Bulk Loading

The straight edge design is specifically suited to applications where a clean, undamaged cutting surface matters: loading aggregates, sand, gravel, topsoil, and loose fill without the ground disturbance caused by toothed cutting edges. This makes it equally effective for finish grading passes, loading from hard surfaces, and handling materials that would be scattered or damaged by aggressive tooth penetration. For operations that alternate between bulk loading and surface-sensitive work, the straight edge bucket eliminates the need to swap attachments between tasks.

8mm Main Plate | 1,229kg | Sustained Impact and Abrasion Resistance Across Heavy Loading Cycles

Constructed with an 8mm main plate and a total operating weight of 1,229kg, this wheel loader bucket is built to withstand the sustained impact and abrasion of heavy loading cycles without structural fatigue or premature wear to the cutting edge. The robust construction ensures consistent performance across extended work cycles on construction sites, quarries, and agricultural yards where bucket loads are heavy and cycle times are continuous.

Big BM Quick Attach — Fast Secure Coupling to Volvo L35-Class and Larger Wheel Loaders, No Adapters

The Big BM quick-attach bracket provides fast, secure coupling to compatible wheel loaders — including Volvo L35-class machines and larger — without requiring adapters or custom mounting hardware. Big BM is one of the most widely used quick-attach standards on mid-to-large European wheel loaders, making the T-LSB2700 a direct bolt-on addition for any machine already running a Big BM coupler.

Applications — Construction, Earthmoving, Agriculture and Industrial

• Aggregates, sand and gravel — high-volume bulk loading from stockpiles
• Topsoil and loose fill — clean scooping without surface damage
• Finish grading — straight edge for smooth, controlled surface passes
• Hard surface loading — no tooth scatter on paved or compacted surfaces
• Agricultural bulk handling — grain, compost, and loose agricultural materials

Key Features

• 106" (2,700mm) working width — high-volume bulk material handling
• 2.24m³ capacity — mid-size to large wheel loader applications
• Straight edge cutting lip — clean scooping, finish grading, hard surface loading
• 8mm main plate — sustained impact and abrasion resistance
• 1,229kg — heavy-duty construction for continuous loading cycles
• Big BM quick attach — Volvo L35-class and larger, no adapters
• Construction, earthmoving, agriculture and industrial site applications

Technical Drawing:

Specifications
