LANDYINDUS 3-Tine Round Bale Spear | 1,500kg SWL | Dual φ45mm Main Spears | Removable Centre Tine | Conus 2 | Optional Dual-Bale High Back | Euro | T-RBS13

LANDYINDUS T-RBS13 3-Tine Round Bale Spear | 1,500kg SWL | 2×φ45mm Main Spears (1,100 or 1,250mm) | Removable φ36×810mm Centre Tine | Conus 2 Taper Bush | Optional Dual-Bale High Back | Euro Hitch | 100–103kg

The LANDYINDUS T-RBS13 Heavy Duty 3-Tine Round Bale Spear is a high-capacity Euro hitch loader attachment engineered for operators who need to move more bales in less time. With an adjustable high back option that allows two round or square bales to be carried simultaneously in a single loader pass, this bale spear effectively doubles the productivity of standard single-bale handling setups — making it a practical upgrade for farms, ranches, and feedlots where bale movement is a daily, high-volume task.

Optional Dual-Bale High Back — Two Bales Per Pass, Double the Productivity of Single-Bale Setups

The adjustable high back option allows two round or square bales to be carried simultaneously in a single loader pass, effectively doubling throughput compared to standard single-bale spear attachments. For operations where bale movement is a daily, high-volume task, this single feature can halve the total number of loader passes required to move a given quantity of bales — directly reducing fuel consumption, operator time, and machine hours per tonne of hay moved.

Removable Centre Tine — Switch Between 3-Tine and 2-Tine Configuration Without Tools

One of the most versatile features of this bale spear is the removable centre tine design. The central stabilizer spear can be detached when working with certain bale types or sizes that require a wider gap between the main spears, giving the operator the flexibility to switch between a three-tine and two-tine configuration without tools or additional hardware. This adaptability makes the T-RBS13 effective across a broader range of bale handling scenarios than fixed-tine alternatives.

Conus 2 Taper Bush — Play-Free Connection, Consistent Alignment Under Full 1,500kg Load

The frame is built around a welded Conus 2 taper bush mounting system, which provides a secure, play-free connection to Euro hitch front loaders and is compatible with nearly all loader brands and models that use the Euro quick-attach standard. The Conus 2 taper bush design ensures consistent alignment and load transfer between the frame and the loader arm, maintaining structural integrity under the full 1,500kg safe working load.

Two Spear Length Options — 1,100mm or 1,250mm to Match Bale Size and Operator Preference

Bale Handling Series — Full Range Comparison

Key Features

• Optional dual-bale high back — two bales per pass, double single-bale productivity
• Removable centre tine — 3-tine or 2-tine, no tools, broader bale type compatibility
• Conus 2 taper bush — play-free Euro hitch connection, consistent load alignment
• 1,500kg SWL — exceeds 1,000kg common among comparable bale spears
• 2×φ45mm main spears | φ36×810mm centre stabilizer
• 1,100mm or 1,250mm spear length — specify at order
• 100–103kg | Euro hitch — all Euro quick-attach loader brands

Technical Drawing:

Specifications
