LANDYINDUS 4.5T Spreader Beam & Lifting Beam | Crane & Forklift Dual Use | F-FSB2290

LANDYINDUS F-FSB2290 4.5T Spreader Beam & Lifting Beam | Crane & Forklift Dual Use

The LANDYINDUS F-FSB2290 is a heavy-duty 2-in-1 Spreader Beam and Lifting Beam designed for both crane and forklift applications. It is purpose-built for lifting long, awkward, or oversized loads in industrial, construction, and warehouse environments safely and efficiently.

With a 4.5-ton (4,500kg) rated capacity, this multitasking lifting attachment offers unparalleled versatility on the job site without requiring additional dedicated equipment.

Versatile Operating Modes

The F-FSB2290 delivers three distinct operating modes to handle a wide variety of lifting tasks:

1. Crane Mode (Lifting Beam): Lift loads via the centre single hook point for balanced, overhead lifting using an overhead or gantry crane.
2. Crane Mode (Spreader Beam): End-lift using a 2-leg chain sling attached to the crane. This provides wider load distribution, prevents inward crushing forces on long loads, and reduces sling angle stress.
3. Forklift Mode: Insert forklift tines directly into the integrated fork pockets to transport and position long, drooping loads (like timber packs, rebar bundles, or steel extrusions) horizontally with full stability and precision.

Heavy-Duty Structural Integrity

Built from heavy-duty structural steel with a durable finish, the F-FSB2290 is engineered for demanding job sites where versatility and load safety are non-negotiable. With an overall width of 2,286 mm and a solid 180 kg self-weight, it provides the rigid backbone needed to stabilize 4.5 tonnes of unwieldy cargo.

Key Features

• 4.5 Tonne (4,500kg) Maximum Safe Working Load
• 2-in-1 Design: Functions as both a Lifting Beam and Spreader Beam
• Dual-Use: Compatible with Overhead Cranes and Forklifts
• Oversized 188×88mm fork pockets for heavy-duty forklift tines
• Wide 785mm pocket centre spacing for enhanced lateral stability
• Durable structural steel construction (180 kg unit weight)

Specifications

Technical Drawing
