LANDYINDUS 64" Skid Steer Scrap Shears | 360° Continuous Rotation | Straight Lower Jaw | 0–200mm Opening | Hydraulic Metal Cutting | MP1140

LANDYINDUS S-SS1630(64IN)-MP1140 64" Skid Steer Scrap Shears | 360° Continuous Rotation | Straight Lower Jaw | 0–200mm Jaw Opening | Hydraulic Metal Cutting | MP1140 Universal Quick Attach

The LANDYINDUS S-SS1630 Skid Steer Scrap Shears is a hydraulic-powered metal cutting tool built for demolition contractors, scrap metal recyclers, and steel processing operators who need fast, precise cutting of structural steel, rebar, pipe, sheet metal, and mixed scrap material directly from the skid steer cab. With a 64" (1,630mm) frame width and a jaw opening range of 0–200mm, the attachment handles a wide variety of material profiles and cross-sections in a single hydraulic cycle.

360° Continuous Rotation — Align Shear Head to Any Angle from the Cab, No Machine Repositioning Required

The 360-degree continuous rotation system is the defining operational advantage of this hydraulic scrap shear. The operator can rotate the shear head to any angle from the cab without repositioning the machine, allowing precise alignment with structural members, pipe runs, and awkwardly oriented scrap piles — dramatically reducing cycle time on demolition sites and scrap yards where material orientation is unpredictable. This full-rotation capability sets the S-SS1630 apart from fixed-head shears that require the operator to repeatedly reposition the machine to achieve the correct cutting angle.

Unique Straight Lower Jaw — Distributes Material Along Full Jaw Length, Maximises Cutting Force, Fewer Re-Cuts

The unique straight lower jaw design distributes material evenly along the full length of the jaw during each cut, rather than concentrating it at the apex as conventional curved-jaw shears do. This distribution effect maximises the effective cutting force across the entire jaw surface, reducing the risk of material jamming or exceeding the shear’s cutting capacity on dense or compressed scrap bundles. The result is cleaner cuts, fewer re-cuts, and higher throughput per hour on both demolition and scrap processing applications.

16 MPa | 60 LPM | 463kg | Universal MP1140 — Standard Hydraulics, Fast Tool-Free Installation

Operating at 16 MPa with a hydraulic flow requirement of 60 LPM, the S-SS1630 integrates with most standard skid steer auxiliary hydraulic systems — no high-flow upgrade required. At 463kg with overall dimensions of 1,780 × 1,260 × 681mm, the attachment mounts to any skid steer via universal MP1140 quick-attach plate for fast, tool-free installation.

Key Features

• 360° continuous rotation — align to any angle from cab, no machine repositioning
• Unique straight lower jaw — distributes material along full jaw length, maximises cutting force
• Cleaner cuts, fewer re-cuts — higher throughput on demolition & scrap processing
• 0–200mm jaw opening — wide range of material profiles & cross-sections
• 64" (1,630mm) frame width — structural steel, rebar, pipe, sheet metal & mixed scrap
• 16 MPa | 60 LPM — standard skid steer auxiliary hydraulics, no high-flow required
• 1,780×1,260×681mm | 463kg
• Universal MP1140 quick attach — fast tool-free installation on any skid steer
• Demolition contractors, scrap metal recyclers & steel processing operators

Technical Drawing:

Specifications
