LANDYINDUS 66 Inch Skid Steer Hydraulic Landscape Rake | 50° Tilt | Rock Collection & Soil Prep | MP1140

LANDYINDUS S-HRR1680(66IN)-MP1140 Skid Steer Hydraulic Landscape Rake | 66 Inch | 50° Hydraulic Tilt | Rock Collection & Soil Preparation | MP1140 Universal Quick Attach

The LANDYINDUS S-HRR1680 66 Inch Skid Steer Hydraulic Landscape Rake is a professional-grade surface preparation attachment designed for efficient rock collection, debris removal, and soil finishing on lawns, gardens, golf courses, athletic fields, construction site final grades, and any application requiring a clean, level seedbed. At 66" wide with a working width of 1,400mm, this hydraulic landscape rake covers significant ground per pass — reducing total passes needed and cutting overall job time compared to narrower or non-hydraulic rake alternatives.

Dual-Action Rotating Tines — Collect Rocks & Debris While Simultaneously Loosening & Aerating Soil in One Pass

The rotating tines perform two functions simultaneously in a single pass — collecting rocks, brush, and surface debris into the integrated hopper while simultaneously loosening and aerating the soil beneath, leaving the surface ready for seeding, sod laying, or finish grading without requiring a separate tillage pass. This dual-action capability is what separates an active hydraulic landscape rake from passive drag rakes — delivering a finished surface quality that passive attachments require multiple passes to achieve. Tine depth and aggressiveness can be managed through ground speed and down pressure, giving operators control over surface working intensity depending on soil conditions and project requirements.

50° Hydraulic Tilt — Angle the Rake Head from the Cab, No Machine Repositioning on Slopes or Uneven Ground

The standout feature of this skid steer landscape rake is its hydraulic 50-degree tilt capability, which allows the operator to angle the rake head from within the cab without stopping or repositioning the machine. This tilt function is essential for working on sloped terrain, directing collected debris to one side for easier windrow pickup, and maintaining consistent tine contact on uneven ground. The ability to adjust tilt angle on the fly dramatically improves productivity on complex terrain and reduces the machine repositioning time that fixed-angle rakes require.

1,667 × 1,597 × 1,019mm | 708kg — Mass for Consistent Ground Contact & Tine Penetration Across Varying Soil Conditions

Weighing 708kg with overall dimensions of 1,667 × 1,597 × 1,019mm, the attachment provides the mass needed to maintain consistent ground contact and tine penetration across varying soil conditions without bouncing or skipping. The hydraulic system operates at up to 16 MPa with a recommended flow of 60 LPM, integrating with standard skid steer hydraulic circuits without modification. Compatible with most skid steer loaders and compact track loaders via universal MP1140 quick attach.

Use Cases

• Lawn & garden seedbed preparation
• Golf course & athletic field surface finishing
• Construction site final grade cleanup
• Rock & debris collection across large areas
• Sod bed preparation & soil aeration
• Sloped terrain surface work with hydraulic tilt control

Key Features

• Dual-action rotating tines — rock collection + soil loosening & aeration in one pass
• 50° hydraulic tilt — angle from cab, no repositioning on slopes or uneven ground
• 1,400mm working width — significant ground coverage per pass
• Integrated hopper — collects rocks & debris during tine rotation
• Tine depth controlled by ground speed & down pressure — adaptable to soil conditions
• 16 MPa | 60 LPM — standard skid steer hydraulic circuits, no modifications
• 1,667×1,597×1,019mm | 708kg — consistent ground contact across varying terrain
• Universal MP1140 quick attach — most skid steer loaders & compact track loaders

Technical Drawing:

Specifications
