Transform your tractor front-end loader into a versatile, heavy-duty material-handling forklift in minutes with the LANDYINDUS Adjustable Clamp-On Pallet Forks (Model: G-BF Series). Engineered with sliding adjustable fork tines that adjust from 24 to 43 inches (610mm to 1090mm) in width and rated for up to 1,800 kg (approximately 4,000 LB) capacity, this attachment gives you the ultimate versatility for moving pallets, lumber, round logs, fencing, and bulk farm supplies without removing your bucket.
Product Overview
Fixed-width pallet forks force operators to work with standard pallet dimensions only, making it difficult or dangerous to handle narrow skids or extra-wide crates. The LANDYINDUS G-BF Series solves this limitation with an integrated crossbar that permits smooth lateral tine adjustment across a wide 610mm–1090mm range. Available in two heavy-duty configurations—a 1067mm long fork rated for 1800kg (4000 LB) and a compact 762mm fork rated for 680kg (1500 LB)—these forks slide directly over your loader bucket cutting edge and lock down securely with heavy-gauge clamp screws.
Core Selling Points
Adjustable 24" to 43" (610–1090mm) Tine Spacing
Easily match your fork spread to pallets, crates, nursery totes, or odd-sized cargo. The locking collar system allows rapid repositioning and secure tightening across the heavy-duty spreader tube for tailored load support.
Heavy-Duty Tubular Steel & up to 1,800kg (4,000 LB) SWL
Fabricated with thick-walled rectangular structural steel tubing, these forks withstand extreme bending moments and heavy daily commercial use. The 1067mm heavy model supports up to 1,800kg, while the 762mm model delivers 680kg of lifting performance for smaller tractors.
Roll Back Protection & Integrated Chain Holes
Each fork incorporates vertical roll back protection slots to stop round logs, pipes, or shifted cargo from rolling backwards toward your tractor hood or operator station. Pre-cut chain anchoring holes allow operators to strap or chain awkward cargo tightly against the mast before lifting.
Fast, Bolt-On Clamp-Free Installation
No hydraulic lines, welding, or bucket drilling required. Simply align the forks on your bucket cutting edge, slide into position, and hand-tighten the heavy-duty acme screw clamps for rock-solid stability in under five minutes.
Specifications
| Model | Safe Working Load (SWL) | Fork Dimensions (L × W × H) | Adjustable Spacing Range (A) | Weight |
|---|---|---|---|---|
| G-BF70*50*1067-(610-1090) | 1,800 kg (~4,000 LB) | 1067 × 70 × 50 mm | 610 – 1090 mm (24" – 43") | 43 kg |
| G-BF75*50*762-(610-1090) | 680 kg (~1,500 LB) | 762 × 75 × 50 mm | 610 – 1090 mm (24" – 43") | 32 kg |
Technical Drawing
⚠️ Safety & Compatibility Warnings
- Bucket Lip Clamp Torque: Prior to lifting, tighten all clamping bolts firmly against the bucket cutting edge. Re-inspect bolt torque after lifting the first load and periodically during continuous use.
- Weight Distribution & Load Center: Position the load as close to the fork heel (bucket face) as possible. Carrying loads on the fork tips severely reduces bucket lift capacity and increases loader tipping risk.
- Roll Back & Cargo Securing: Utilize the integrated chain tie-down holes and roll back protection slots when transporting logs, pipes, or unpalletized cargo to prevent material from sliding backward onto the loader arms.
- Loader Rating Adherence: Never exceed the rated Safe Working Load of the forks or the maximum lifting capacity of your tractor front loader, whichever is lower.
