LANDYINDUS Automatic Dual Drum Forklift Lifter | 1,000kg SWL | Lifts 2 × 205L Steel Drums Simultaneously | Drive-Forward Auto-Engage Both Drums | Self-Tightening Load Response | Zinc-Plated | 165×65mm Fork Pockets | F-SDL2

LANDYINDUS F-SDL2 Automatic Dual Drum Forklift Lifter | 1,000kg SWL | Lifts 2 × 205L Steel Drums Simultaneously — One Forward Motion, Both Drums Locked | Self-Tightening Load Response on Each Drum | Zinc-Plated | 165×65mm Fork Pockets | 600mm Centres

The LANDYINDUS F-SDL2 Automatic Dual Drum Forklift Lifter is a heavy-duty zinc-plated drum handling attachment engineered to lift, transport, and place two standard 205-litre steel drums simultaneously in a single forklift pass — delivering twice the throughput of single-drum operations without additional equipment, operators, or cycles. The F-SDL2 combines the fully automatic drive-forward engagement of the F-SDL1 with the dual-drum capacity of the F-BGN2 — the highest-efficiency drum handling solution in the LANDYINDUS series.

One Forward Motion — Both Drums Automatically Engaged Simultaneously

The fully automatic clamping mechanism operates on both drums simultaneously with a single forward driving motion:

• Align: position the forklift so the adjustable support arms align with the centre of each drum
• Engage: drive forward — the arms automatically engage around both drum bodies and lock under each drum’s rolling hoop as the forks are raised. No manual adjustment between drums. No secondary securing steps. No dismounting.
• Transport: both drums gripped, lifted, and ready in one seamless operation
• Release: lower to ground, reverse — both arms disengage automatically, drums placed precisely

Self-Tightening Load Response on Each Drum — Dual Independent Grip Assurance

The self-tightening load response mechanism operates independently on each drum. As the combined weight of the two drums increases downward force on the clamping arms, grip on each drum automatically tightens in proportion to the total load. This self-reinforcing dual clamping eliminates the risk of single-drum slippage or differential movement — a failure mode where one drum shifts while the other remains held — that can occur with less sophisticated dual clamping systems under dynamic load conditions on uneven ground.

Complete Drum Lifter Series — All 4 Models Compared

600mm Fork Pocket Centres — Widest in the Series, Dual-Drum Stance

The F-SDL2 uses 165×65mm fork pockets at 600mm centres — the widest centre spacing in the drum lifter series — specifically engineered to accommodate two standard 205-litre drums side by side within the 1,189mm attachment width. Confirm your forklift fork spacing can be set to 600mm centres before ordering.

Zinc-Plated Finish — Corrosion Resistance for Chemical & Outdoor Environments

The zinc-plated finish provides superior long-term corrosion resistance in humid warehouses, outdoor chemical storage yards, and corrosive industrial environments — matching the F-BGN2 finish standard and outperforming standard painted steel attachments in demanding conditions.

Applications

• High-volume chemical warehouses — maximum drum cycle efficiency, zinc corrosion resistance
• Oil & lubricant storage yards — outdoor zinc protection, dual automatic steel drum handling
• Manufacturing facilities — high-cycle 205L steel drum inventory, self-tightening dual grip
• Industrial distribution centres — large daily drum volumes, 50% cycle reduction vs single

Key Features

• Lifts 2 × 205L steel drums simultaneously — 50% fewer forklift cycles
• Drive-forward auto-engage both drums — one motion, no dismounting, no manual steps
• Self-tightening load response — independent on each drum, no differential slippage
• Mechanical hoop lock — cannot accidentally disengage during lift or transport
• 1,000kg SWL | 165×65mm fork pockets | 600mm centres | 1,340mm load centre
• Zinc-plated finish — corrosion resistance
• 85kg — lightweight dual-drum automatic solution

Specifications

Technical Drawing
