Product Overview
Need mini-excavator trenching performance without the cost of renting a dedicated machine? The LANDYINDUS G-COQS-700 Clamp-On Digging Spade mounts directly to loader buckets and pallet fork tines with a 700mm reach and 10mm high-strength steel blade.
The LANDYINDUS G-COQS-700 is a versatile clamp-on digging spade attachment engineered to instantly convert standard skid steer buckets, tractor front-end loaders, and pallet fork blades into high-penetration trenching spades. Built with heavy-duty triangular gusset reinforcement, a heavy 10mm plate blade, and an integrated safety chain hook, it powers through compacted clay, hardpan soil, irrigation ditches, and stubborn root systems.
Core Selling Points
- Dual Loader Bucket & Pallet Fork Mounting: Dual-mount pocket design clamps firmly onto loader cutting edges or standard forklift tines without requiring hydraulic remotes or pin changes.
- Deep 700mm Penetration & 10mm Solid Steel Blade: Heavy 10mm thick structural steel spade blade cuts cleanly through packed soil and tree roots without bending or twisting.
- Integrated Safety Chain Hook: Built-in safety chain restraint loop locks the attachment to the bucket back-lip, preventing the spade from walking off under heavy breakout forces.
- Heavy-Duty Triangular Gusset Bracing: Welded structural triangulation distributes high-impact digging stresses across the entire mounting frame for exceptional fatigue resistance.
Specifications
| Type | Overall Dimension (L×W×H) / mm | Spade Blade Length / mm | Blade Thickness / mm | Compatibility | Weight / kg |
|---|---|---|---|---|---|
| G-COQS-700 | 1145×459×204 | 700 | 10 | Loader Buckets & Pallet Fork Blades | 43 |
Technical Drawing
⚠️ Safety & Compatibility Warnings
- Safety Chain Engagement Mandatory: Always secure and tension the safety binder chain between the integrated spade chain hook and the host machine bucket/carriage before operating.
- Clamp Bolt Pre-Shift Inspection: Torque down all clamping bolts firmly before beginning work. Re-check clamp bolt torque after the first 15 minutes of ground penetration.
- Underground Utility Locating: Always scan for and locate buried gas pipelines, electrical cables, water mains, and optical fiber lines before digging trenches.
- Hydraulic Prying Thresholds: Designed for earthmoving, trenching, and soil loosening. Do not apply violent side-loading or attempt to lever immovable bedrock beyond machine breakout limits.
