LANDYINDUS Double Tine Bale Spear | 39" (990mm) Tine Spacing | 2×φ36×1,250mm | Wide-Stance Load Distribution | Euro | Front Loader | T-BS

LANDYINDUS T-BS Double Tine Bale Spear | 39" (990mm) Tine Spacing | 2×φ36×1,250mm Main Spears | Wide-Stance Load Distribution | Euro Bracket | Front Loader | 69kg

The LANDYINDUS T-BS Double Tine Bale Spear is a heavy-duty front loader attachment purpose-built for moving square bales and medium-to-large round bales with speed, stability, and confidence. Designed to mount directly onto a Euro bracket front end loader, this bale spear is compatible with a wide range of standard tractors and material handlers.

39" (990mm) Tine Spacing — Wide-Stance Load Distribution, Reduces Bale Deformation vs Single-Spear

The defining feature of the T-BS is its two-tine configuration with tines spaced 39 inches (990mm) apart, providing sufficient width to support broader bales securely during lifting and transport. This wider spacing distributes the load more evenly across the bale, reducing the risk of bale deformation or instability mid-lift — a common issue with single-spear designs. The wide stance is particularly effective for square bales, which have a flat base that benefits from two widely-spaced support points rather than a single central spear.

2×φ36×1,250mm Main Spears — Clean Penetration, Secure Hold Without Pushing or Rolling

Each φ36×1,250mm main spear is engineered to penetrate bales cleanly and hold them firmly throughout the entire handling cycle, from pickup to placement, without pushing or rolling the bale off course. The 1,250mm length provides deep penetration for large-format bales, while the φ36mm diameter is optimized for clean entry without excessive bale damage.

Euro Bracket — Wide Front Loader Compatibility, No Additional Adapters

The Euro bracket compatibility ensures the T-BS fits a wide range of standard front end loaders and material handlers without additional adapters. At 69kg, the attachment offers a practical balance between structural strength and ease of attachment and removal.

T-BS Double Tine vs Single-Spear vs 3-Tine — Which Bale Spear Configuration?

Key Features

• 39" (990mm) tine spacing — wide-stance, even load distribution across bale width
• 2×φ36×1,250mm main spears — clean penetration, no pushing or rolling
• Optimized for square bales and medium-to-large round bales
• Euro bracket — wide front loader compatibility, no adapters
• 69kg | 1,326×1,210×533mm — practical strength-to-weight ratio
• Heavy-duty steel — repeated daily use, demanding farm environments

Technical Drawing:

Specifications
