LANDYINDUS Excavator Blade-Mounted Self-Dumping Hopper | 0.5–1.5m³ | Tipping Skip Dumper

LANDYINDUS E-BGD Series Excavator Blade-Mounted Self-Dumping Hopper | 0.5–1.5m³ | Tipping Skip Dumper

The LANDYINDUS E-BGD Series Excavator Blade-Mounted Tipping Dumper is a heavy-duty material transport and handling solution that attaches directly to the blade of a standard excavator, transforming the machine into a self-sufficient material mover capable of loading, transporting, and self-dumping bulk materials across construction sites, mining operations, civil works projects, and any terrain where conventional wheeled dumpers, forklifts, or manual handling methods are impractical or unsafe. Available in three capacities — 0.5 m³, 1.0 m³, and 1.5 m³ — and manufactured from 3 mm heavy-gauge steel plate throughout, the E-BGD series provides a robust, purpose-engineered attachment for moving soil, rubble, aggregate, demolition debris, and bulk materials without relying on additional plant or ground crew.

Goes Where Wheeled Dumpers Cannot — Blade-Mounted for Any Terrain

The defining advantage of the blade-mounted design is the excavator's ability to carry the loaded dumper across terrain that would be impassable for wheeled or tracked dumpers operating independently. Mounting directly to the excavator's dozer blade via adjustable blade mounts compatible with virtually any excavator configuration, the E-BGD travels with the machine across slopes, soft ground, muddy conditions, rocky terrain, and confined site areas — making it particularly valuable on remote construction sites, hillside civil works, underground or basement excavation projects, and any application where a separate transport vehicle would represent additional cost and logistical complexity.

Single-Operator Load, Transport & Self-Dump Cycle — No Ground Crew Required

The operator uses the excavator's own bucket to load the dumper directly from the excavation face or stockpile, then repositions the machine to the desired dump location. At the dump point, the hopper tilts forward under the operator's control, discharging the full load cleanly and completely without manual intervention, spillage, or a second operator. This single-operator, self-contained workflow eliminates coordination delays, labour costs, and safety risks associated with ground crew-assisted material handling in active excavation zones.

Three Capacities — 0.5m³ to 1.5m³ for Every Excavator Class

• E-BGD500 — 1300×1234×840mm | 3mm plate | 0.5m³ | 145kg | Compact excavators & confined site conditions
• E-BGD1000 — 1720×1424×1065mm | 3mm plate | 1.0m³ | 221kg | Mid-size excavators & general construction
• E-BGD1500 — 1845×1586×1093mm | 3mm plate | 1.5m³ | 330kg | Large excavators & high-volume civil, mining & demolition

3mm Heavy-Gauge Steel — Built for Continuous Heavy-Cycle Operation

Manufactured from 3 mm heavy-gauge steel plate throughout, the E-BGD series is engineered to withstand the repeated impact, abrasion, and load cycles of continuous bulk material transport in demanding construction, mining, and demolition environments. The adjustable blade mount system ensures compatibility with a wide range of excavator makes and models without modification to the host machine.

Key Features

• Blade-mounted — travels with the excavator across any terrain wheeled dumpers cannot access
• Single-operator load, transport & self-dump cycle — no ground crew required
• Self-tipping hopper — operator-controlled forward tilt, clean full discharge
• Three capacities: 0.5m³, 1.0m³, 1.5m³ for compact to large excavators
• 3mm heavy-gauge steel plate construction throughout
• Adjustable blade mounts — fits virtually any excavator make and model
• No modification to host machine required
• Ideal for remote sites, slopes, confined areas & underground excavation

Technical Drawing:

Specifications
