LANDYINDUS Extreme-Duty Skid Steer GP Bucket | 12mm Plate 20mm Cutting Edge 63" to 84" Quick Attach
Built for operators who push their equipment to the limit. The LANDYINDUS Extreme-Duty General Purpose Skid Steer Bucket is engineered for the most demanding loading, digging, and material handling applications in construction, demolition, mining, and large-scale earthmoving operations where standard-duty buckets simply wear out too fast. With a 12mm high-grade steel plate shell and reinforced back structure, this is the GP bucket built to outlast the job.
20mm Hardened Cutting Edge — Superior Penetration & Wear Resistance
At the core of this extreme-duty bucket is a 20mm hardened cutting edge that delivers superior ground penetration and wear resistance on the toughest surfaces — compacted gravel, rocky soil, broken concrete, and heavy clay. The thick cutting edge significantly outlasts the thinner edges found on economy and standard-duty buckets, reducing replacement frequency and lowering long-term operating costs for high-volume operations. When you're digging hard ground every day, the cutting edge is where the money is saved.
12mm High-Grade Steel Plate Shell — Extreme-Duty Structural Integrity
The 12mm high-grade steel plate shell and reinforced back structure are engineered to withstand the repetitive impact and lateral stress of heavy daily use in construction, demolition, and mining environments. Where standard 6mm or 8mm buckets flex, crack, or deform under extreme load cycles, the LANDYINDUS extreme-duty shell holds its geometry and keeps working.
Extended Base Design — Clear Cutting Edge Visibility
The extended base design provides operators with a clear and unobstructed line of sight to the cutting edge during operation — improving precision and reducing the risk of over-digging or material spillage. This visibility advantage is especially valuable in tight job site conditions where accurate bucket placement directly impacts productivity and safety.
8 Width Options — 63" to 84" for Every Machine Size
Available in eight widths: 63", 64", 66", 68", 72", 74", 78", and 84", with volume capacities ranging from 0.42m³ (63") to 0.68m³ (84") — match the bucket precisely to your machine size and job site payload requirements.
Key Features
- 12mm high-grade steel plate shell with reinforced back structure
- 20mm hardened cutting edge — superior wear resistance vs. economy and standard-duty alternatives
- Extended base design for clear cutting edge visibility from the cab
- 8 width options: 63", 64", 66", 68", 72", 74", 78", and 84"
- Volume range: 0.42m³ to 0.68m³
- Universal skid steer quick attach — no additional adapters required
- Built for construction, demolition, mining, and heavy earthmoving
Technical Drawing:
Specifications
| Model | Dimensions (W×D×H) | Plate Thickness | Volume | Weight |
|---|---|---|---|---|
| S-HDGP1600(63IN)-MP1140 | 1600×883×542 mm | 12 mm | 0.42 m³ | 237 kg |
| S-HDGP1630(64IN)-MP1140 | 1630×883×542 mm | 12 mm | 0.43 m³ | 242 kg |
| S-HDGP1680(66IN)-MP1140 | 1680×883×542 mm | 12 mm | 0.45 m³ | 249 kg |
| S-HDGP1730(68IN)-MP1140 | 1730×883×542 mm | 12 mm | 0.48 m³ | 255 kg |
| S-HDGP1830(72IN)-MP1140 | 1830×883×542 mm | 12 mm | 0.53 m³ | 268 kg |
| S-HDGP1880(74IN)-MP1140 | 1880×883×542 mm | 12 mm | 0.55 m³ | 274 kg |
| S-HDGP1980(78IN)-MP1140 | 1930×883×542 mm | 12 mm | 0.58 m³ | 285 kg |
| S-HDGP2130(84IN)-MP1140 | 2130×883×542 mm | 12 mm | 0.68 m³ | 302 kg |
