LANDYINDUS Extreme-Duty Skid Steer Round Bar Rock Bucket | Reinforced Tines Webbed Cutting Edge 66" to 82" Rock Removal Quick Attach

SKU: S-HDSB2440(96IN)-MP1140
Get a Quote

Got questions?

Feel free to get in touch

Ask an expert!

Chat Email +(1) 657-271-9801

LANDYINDUS Extreme-Duty Skid Steer Round Bar Rock Bucket | Reinforced Tines Webbed Cutting Edge 66" to 82" Rock Removal Quick Attach

Standard round bar rock buckets break tines. This one doesn't. The LANDYINDUS Extreme-Duty Round Bar Rock Bucket is engineered for operators who push their equipment to the limit on large-scale rock removal, land clearing, and heavy debris cleanup operations. Built specifically for large skid steer loaders, this extreme-duty attachment is designed to outperform standard round bar rock buckets in both structural strength and long-term tine durability under the most demanding job site conditions — available in five widths from 66" to 82".

Reinforced Round Bar Tines + Webbed & Chamfered Cutting Edge — Higher Strength at Every Connection Point

At the core of this rock bucket's performance is its reinforced round bar tine system (30mm diameter), integrated directly into a webbed and chamfered cutting edge. This construction method significantly increases the strength of each tine connection point compared to conventional welded designs — reducing the risk of tine failure when working through dense rock, compacted soil, and heavy debris. The result is a rock bucket that holds up to repeated extreme-duty use without compromising structural integrity, cycle after cycle.

Enclosed Cross-Member — Added Rigidity & Impact Resistance

The enclosed cross-member at the base of the bucket adds an additional layer of rigidity and impact resistance — making it ideal for high-volume rock and debris handling on commercial construction, agricultural, and land clearing sites. Where open-frame designs flex under heavy lateral load, the enclosed cross-member keeps the bucket geometry stable under repeated impact.

Forward-Sloped Top Cross-Member — Enhanced Operator Sightlines

The forward-sloped top cross-member improves operator sightlines during work — enhancing both safety and precision when maneuvering in tight or complex terrain. Clear visibility of the tine tips and cutting edge means more accurate bucket placement on every pass.

5 Width Options — 66" to 82" for Large Skid Steer Loaders

Available in five widths: 66", 70", 74", 78", and 82" with volume capacities from 0.28m³ to 0.35m³. Fits most major skid steer brands including Bobcat, Case, Caterpillar, John Deere, and Kubota via a universal quick-attach mounting system.

Key Features

  • Reinforced 30mm round bar tines integrated into webbed & chamfered cutting edge — higher tine connection strength vs. standard welded designs
  • Enclosed cross-member for added rigidity and impact resistance under heavy load
  • Forward-sloped top cross-member for enhanced operator sightlines
  • 56mm tine spacing for efficient rock retention and debris separation
  • 5 width options: 66", 70", 74", 78", and 82"
  • Volume range: 0.28m³ to 0.35m³
  • Compatible with Bobcat, Case, Caterpillar, John Deere, Kubota & universal quick attach systems

Technical Drawing:

Specifications

Model Dimensions (W×D×H) Bar Dia. Spacing Volume Weight
S-RRB1680(66IN)-MP1140 1680×920×560 mm 30 mm 56 mm 0.28 m³ 262 kg
S-RRB1780(70IN)-MP1140 1780×920×560 mm 30 mm 56 mm 0.30 m³ 269 kg
S-RRB1880(74IN)-MP1140 1880×920×560 mm 30 mm 56 mm 0.32 m³ 280 kg
S-RRB1980(78IN)-MP1140 1980×920×560 mm 30 mm 56 mm 0.33 m³ 292 kg
S-RRB2080(82IN)-MP1140 2080×920×560 mm 30 mm 56 mm 0.35 m³ 308 kg
