LANDYINDUS F-SFJL10 Fixed Long Jib Boom | 10T Ultimate Heavy-Duty SWL | 3.56m Max Reach | Wide Pocket Design | Zinc Plated
The LANDYINDUS F-SFJL10 Fixed Long Jib Boom is the ultimate heavy-duty forklift jib attachment in our range, engineered for the most extreme long-reach lifting operations across heavy port handling, large-scale construction, offshore industrial facilities, and ultra-heavy manufacturing environments.
Rated at a monumental 10,000 kg (10 tonnes) safe working load (SWL) — the absolute highest capacity in our entire forklift jib series — this attachment sets the benchmark for heavy forklift crane attachments where load weights, reach requirements, and structural demands exceed the capability of all standard alternatives.
Wide Pocket Design — Built for 10-Tonne Class Forklifts
Heavy-duty forklifts in the 10-tonne class feature massive tines and are frequently equipped with hydraulic tine positioners (fork spreaders). Standard narrow-pocket jibs simply cannot fit these machines.
The F-SFJL10 is purpose-built to solve this. It features massive 230 × 100 mm fork pockets and an exceptional 875 mm pocket centre spacing (and an overall attachment width of 1,075 mm). This ensures perfect compatibility with specialized high-capacity forklift fleets used in port terminals, large-format steel fabrication yards, and heavy precast concrete facilities.
3.56m Extended Reach | 10-Tonne Lifting Power
Featuring a maximum extended reach of 3.56 metres with a retracted length of 2.19 metres (2,190 mm), this jib provides the extreme horizontal clearance required to lift multi-tonne loads over deep trenches, reach deep into shipping containers, or place massive precast concrete elements across large spans.
To safely manage the immense leverage forces generated when lifting 10,000 kg loads, the attachment features a massive 515 kg heavy-duty steel structure. It operates as a fixed-angle jib, delivering a highly stable, rigid lifting geometry that is ideal for straight vertical lifts and precision load positioning.
Premium Zinc Plated Finish
Unlike standard painted heavy attachments, the F-SFJL10 is finished with a durable zinc plated coating. It is engineered to withstand the harshest outdoor industrial conditions, including prolonged exposure to salt air, moisture, and chemical agents common to coastal construction sites, port facilities, and open-air mining operations.
Tool-Free Slip-On Installation
Despite its massive 10-tonne capacity and 515 kg self-weight, the slip-on design allows site crews to mount and dismount the jib as operational requirements change — eliminating the need for dedicated crane equipment or specialist installation labour. The attachment is secured by a heavy-duty safety chain retention system, providing a critical secondary securing point during operation.
Key Features
- 10.0 Tonne (10,000kg) Ultimate Maximum Safe Working Load
- Telescopic inner beam extends to 3.56 metres
- Wide pocket design (875mm centres) — compatible with hydraulic tine positioners
- Massive 230×100mm fork pockets for heavy-duty 10T+ forklift tines
- Premium zinc plated finish — extreme outdoor/coastal corrosion resistance
- Fixed horizontal angle for maximum structural rigidity
- Slip-on design with heavy-duty safety chain locking
- 515kg heavy-duty steel construction
Specifications
| Model | SWL | Dimensions L×W×H (mm) | Fork Pocket (mm) | Pocket Centres (mm) | Weight (kg) |
|---|---|---|---|---|---|
| F-SFJL10 | 10.0T | 2,190×1,075×516 | 230×100 | 875 | 515 |
Technical Drawing
1. Extreme Leverage & Load De-rating: A 3.56-metre reach combined with a 10.0T rating creates immense leverage forces. The 10.0T SWL applies ONLY when the jib is fully retracted. As the jib extends outward, the lifting capacity drops drastically. You MUST consult the load chart on the attachment and cross-reference it with your forklift's de-rated capacity chart before lifting.
2. Heavy-Duty Pocket & Width Verification: Verify your forklift tines will fit within the massive 230×100mm pockets and can be spread to match the extreme 875mm pocket centres. Do not attempt to use this on standard narrow-carriage forklifts.
3. Safety Chain Requirement: The safety chain must be wrapped around the forklift carriage and secured tightly before lifting.
