LANDYINDUS Forklift Fixed Long Jib Boom | 5T Heavy-Duty | 3.5m Reach | Zinc Plated | F-FJL5

LANDYINDUS F-FJL5 Fixed Long Jib Boom | 5.0T Heavy-Duty SWL | 3.5m Max Reach | Zinc Plated | Slip-On

The LANDYINDUS F-FJL5 Fixed Long Jib Boom is the highest-capacity forklift jib attachment in our range, engineered for heavy-duty long-reach lifting operations across construction, mining, port, and large-scale industrial environments.

Rated at a massive 5,000 kg (5.0T) safe working load (SWL), this fixed long jib delivers the structural strength and reach capability needed for the most demanding overhead lifting tasks — where lower-capacity jib attachments cannot safely perform.

3.5m Extended Reach | 5-Tonne Lifting Power

Featuring a maximum extended reach of 3.5 metres with a compact retracted length of 2.1 metres (2,100mm), this jib provides the extreme horizontal clearance required to lift heavy loads over trenches, reach into shipping containers, or place precast concrete across large spans.

Despite its massive 5-tonne lifting capability, the F-FJL5 weighs just 170kg. This exceptional strength-to-weight ratio ensures that the maximum possible lifting capacity of your 5-tonne host forklift is preserved for the payload itself.

Fixed Angle Design — Maximum Structural Rigidity

As a fixed long jib, the F-FJL5 delivers a highly stable, rigid lifting geometry that is ideal for straight vertical lifts, overhead placements, and precision load positioning. In heavy-duty environments like port loading and precast concrete handling, consistent boom angle and maximum structural rigidity are prioritised over adjustable tilt functionality.

The fixed design eliminates mechanical complexity, simplifies operator training, and provides a reliable, low-maintenance lifting solution for high-frequency operational environments.

Tool-Free Slip-On Installation with Safety Chain

The fork-mounted slip-on design allows the F-FJL5 to install directly onto standard forklift forks without welding, drilling, or permanent modification to the host machine. It features oversized 185×75mm fork pockets set at 275mm centres to accommodate the thicker, wider tines standard on 5-tonne class forklifts.

The attachment is secured by a heavy-duty safety chain retention system. This provides a critical secondary securing point during operation, preventing accidental jib displacement under dynamic load conditions and ensuring operator safety throughout the full lift-and-place cycle.

Premium Zinc Plated Finish

Finished with a durable zinc plated coating, the 5-tonne fixed long jib is built to withstand the harshest outdoor industrial conditions. It provides long-term corrosion resistance against prolonged exposure to moisture, salt air, chemicals, and abrasive environments common to port facilities, coastal construction sites, and open-air mining operations.

Key Features

• 5.0 Tonne (5,000kg) Maximum Safe Working Load
• Telescopic inner beam extends to 3.5 metres
• Fixed horizontal angle for maximum structural rigidity
• Premium zinc plated finish — extreme outdoor corrosion resistance
• Slip-on design with heavy-duty safety chain locking
• Oversized 185×75mm fork pockets for heavy-duty 5T forklift tines
• Weighs just 170kg — exceptional capacity-to-weight ratio

Specifications

For operations requiring a lower capacity, consider our 2.5T (F-FJL2.5) and 4.5T (F-FJCL45) fixed long jib models.

Technical Drawing
