LANDYINDUS Forklift Fixed Long Jib Boom | 7.5T Ultra Heavy-Duty | 3.56m Reach | Wide Pocket | F-SFJL7.5

LANDYINDUS F-SFJL7.5 Fixed Long Jib Boom | 7.5T Ultra Heavy-Duty SWL | 3.56m Max Reach | Wide Pocket Design

The LANDYINDUS F-SFJL7.5 Fixed Long Jib Boom is the flagship ultra heavy-duty forklift jib attachment in our range, engineered for the most demanding long-reach lifting operations across heavy construction, port handling, mining, and large-scale industrial environments.

Rated at a massive 7.5 tonnes (7,500kg) safe working load (SWL) — the highest capacity in our entire forklift jib series — this fixed long jib provides the structural strength, reach, and load security needed for heavy lifting tasks that lower-capacity jib attachments simply cannot safely perform.

Wide Pocket Design — Engineered for Hydraulic Tine Positioners

A critical challenge with heavy-duty forklifts is that many are equipped with hydraulic tine positioners (fork spreaders), which standard jibs cannot accommodate. The F-SFJL7.5 is designed specifically to solve this compatibility gap.

With an oversized pocket size of 180 × 80 mm and an exceptional 875 mm pocket centre spacing (and an overall attachment width of 1,075 mm), this wide-pocket jib boom is purpose-built for heavy-duty forklifts running advanced, wide-spread fork configurations. This makes it the go-to choice for port terminals, heavy equipment yards, and precast concrete facilities.

3.56m Extended Reach | 7.5-Tonne Lifting Power

Featuring a maximum extended reach of 3.56 metres with a retracted length of 2.19 metres (2,190 mm), this jib provides the extreme horizontal clearance required to lift multi-tonne loads over trenches, reach into shipping containers, or place massive precast concrete elements across large spans.

Weighing 450 kg, the attachment's heavy-duty steel structure is built to handle the immense leverage forces generated when lifting 7,500 kg loads.

Supplied with Swivel Hook & Shackle

The F-SFJL7.5 is supplied complete with a heavy-duty safety swivel hook and shackle, ready for immediate deployment with standard lifting chains, slings, and rigging equipment. The swivel hook design allows the load to rotate freely during lifting, preventing dangerous sling twist and load spin that can compromise operator safety and load integrity during complex overhead lifts.

Tool-Free Slip-On Installation with Safety Chain

Featuring a slip-on fork-mounted design, the F-SFJL7.5 installs directly onto standard wide-pocket forklift forks without welding, drilling, or permanent modification to the host machine. Despite its massive capacity, site crews can still mount and dismount the jib as operational requirements change.

The attachment is secured by a heavy-duty safety chain retention system. This provides a critical secondary securing point during operation, preventing accidental jib displacement under dynamic load conditions or sudden braking.

Key Features

• 7.5 Tonne (7,500kg) Flagship Maximum Safe Working Load
• Telescopic inner beam extends to 3.56 metres
• Wide pocket design (875mm centres) — compatible with hydraulic tine positioners
• Oversized 180×80mm fork pockets for heavy-duty 7T+ forklift tines
• Supplied complete with heavy-duty safety swivel hook and shackle
• Slip-on design with heavy-duty safety chain locking
• Massive 450kg heavy-duty steel construction

Specifications

Technical Drawing
