LANDYINDUS Forklift Fixed Short Jib Boom | 10T Ultimate Heavy-Duty | 2.0m Reach | Wide Pocket | F-SFJS10

LANDYINDUS F-SFJS10 Fixed Short Jib Boom | 10T Ultimate Heavy-Duty SWL | 2.0m Max Reach | Wide Pocket Design | Zinc Plated

The LANDYINDUS F-SFJS10 Fixed Short Jib Boom is the highest-capacity compact forklift jib attachment available in our range — and one of the most powerful slip-on forklift crane attachments on the market.

Rated at a massive 10,000 kg (10 tonnes) safe working load (SWL), this 10T short fixed jib delivers maximum lifting capability within a space-efficient profile. It is purpose-built for heavy industrial facilities, port terminals, large-format manufacturing plants, and confined-space environments where load weights reach the absolute upper limits of fork-mounted lifting equipment.

Wide Pocket Design — Built for 10-Tonne Class Forklifts

Heavy-duty forklifts in the 10-tonne class feature massive tines and are frequently equipped with hydraulic tine positioners (fork spreaders). Standard short-reach jibs simply cannot fit these machines.

The F-SFJS10 is purpose-built to solve this. It features massive 230 × 100 mm fork pockets and an exceptional 875 mm pocket centre spacing (with an overall attachment width of 1,125 mm). This ensures perfect compatibility with specialized high-capacity forklift fleets running wide-spread fork configurations.

Compact 2.0m Reach — 10-Tonne Indoor Lifting Power

As the largest capacity short jib in our range, the F-SFJS10 is engineered to perform where no other slip-on forklift jib attachment can. With a maximum extended reach of 2.0 metres and a retracted length of just 1.39 metres (1,390 mm), it delivers 10,000 kg lifting capacity in a footprint that fits within the spatial constraints of indoor workshops, covered equipment yards, and narrow-aisle heavy manufacturing environments.

The fixed jib design provides a stable, rigid lifting geometry that eliminates mechanical complexity and ensures consistent, repeatable lift performance across high-frequency maximum-load operational cycles.

Premium Zinc Plated Finish

Finished with a durable zinc plated coating, the 10-tonne short fixed jib is built to withstand the harshest industrial conditions — including prolonged exposure to moisture, salt air, chemical agents, and abrasive environments common to port facilities, coastal construction sites, and heavy outdoor industrial operations.

Tool-Free Slip-On Installation

The slip-on fork-mounted design allows the F-SFJS10 to install directly onto compatible wide-pocket forklift forks without welding, drilling, or permanent modification to the host machine. To withstand the immense leverage forces generated when lifting 10,000 kg loads, the attachment features a massive 400 kg heavy-duty steel structure.

The attachment must be secured to the forklift carriage by a heavy-duty safety chain retention system. This provides a critical secondary securing point, preventing accidental jib displacement under dynamic load conditions or sudden braking.

Key Features

• 10.0 Tonne (10,000kg) Ultimate Maximum Safe Working Load
• Compact telescopic inner beam extends to 2.0 metres
• Retracts to just 1,390mm for tight indoor manoeuvring
• Wide pocket design (875mm centres) — compatible with hydraulic tine positioners
• Massive 230×100mm fork pockets for heavy-duty 10T+ forklift tines
• Premium zinc plated finish — extreme outdoor/coastal corrosion resistance
• Fixed horizontal angle for maximum structural rigidity
• Slip-on design with heavy-duty safety chain locking
• 400kg heavy-duty steel construction

Specifications

For operations requiring greater reach at the same 10-tonne capacity, consider our F-SFJL10 fixed long jib (3.56m reach).

Technical Drawing
