LANDYINDUS Forklift Fixed Short Jib Boom | 5T Heavy-Duty | 1.96m Reach | Zinc Plated | F-FJS5

LANDYINDUS F-FJS5 Fixed Short Jib Boom | 5.0T Heavy-Duty SWL | 1.96m Max Reach | Zinc Plated | Compact Slip-On

The LANDYINDUS F-FJS5 Fixed Short Jib Boom is the highest-capacity compact forklift jib attachment in our range, delivering a massive 5,000 kg (5.0T) safe working load (SWL) within a space-efficient profile purpose-built for confined spaces, indoor facilities, and tight operational environments.

As the top-capacity model in our fixed short jib series, the F-FJS5 is engineered for operations that demand the highest lifting capability in a compact attachment format — including heavy machinery component handling, large-format equipment maintenance, and industrial assembly tasks where available floor space restricts the use of longer boom attachments.

Compact 1.96m Reach — 5-Tonne Lifting in Tight Spaces

With a maximum extended reach of 1.96 metres and a retracted length of just 1.3 metres (1,300 mm), this 5-tonne short fixed jib provides heavy-duty crane-style lifting capability in workshops, warehouses, manufacturing floors, and narrow-aisle facilities where full-length jib booms (like our 3.5m F-FJL5) cannot safely manoeuvre.

The fixed jib design delivers a stable, rigid lifting geometry that simplifies operator training, eliminates mechanical complexity, and ensures consistent, repeatable lift performance across high-frequency operational cycles.

Highest Capacity-to-Footprint Ratio

Measuring 1,300 × 475 × 500 mm and weighing just 120 kg, the F-FJS5 offers the highest capacity-to-footprint ratio in our forklift jib attachment range. It minimizes added stress on the host forklift, ensuring the machine's maximum lifting capability is preserved for the payload rather than wasted on lifting a heavy attachment.

Tool-Free Slip-On Installation with Safety Chain

Featuring a slip-on mounting design, the F-FJS5 installs directly onto standard forklift forks in minutes — no welding, no drilling, and no permanent modification to the host machine.

The 185 × 75 mm pocket size and 275 mm pocket centres ensure broad compatibility with the thicker, heavier standard forklift tines found on 5-tonne class machines. A heavy-duty safety chain retention system provides a critical secondary securing point, preventing accidental jib displacement under dynamic load conditions or sudden braking.

Premium Zinc Plated Finish

Finished with a durable zinc plated coating, the 5-tonne short fixed jib is built to resist corrosion and surface degradation across both indoor and outdoor operational environments. It provides reliable long-term protection against moisture, chemical exposure, and general abrasion — significantly extending service life compared to standard painted steel alternatives.

Key Features

• 5.0 Tonne (5,000kg) Maximum Safe Working Load
• Compact telescopic inner beam extends to 1.96 metres
• Retracts to just 1,300mm for tight indoor manoeuvring
• Fixed horizontal angle for maximum structural rigidity
• Premium zinc plated finish — extreme corrosion resistance
• Slip-on design with heavy-duty safety chain locking
• Oversized 185×75mm fork pockets for heavy-duty 5T forklift tines
• Weighs just 120kg — exceptional capacity-to-weight ratio

Specifications

For operations requiring greater reach at the same 5-tonne capacity, consider our F-FJL5 fixed long jib (3.5m reach).

Technical Drawing
