Product Overview
Need to align pallets perfectly without repositioning your forklift? The LANDYINDUS Hydraulic Forklift Side Shifter Attachment delivers precise lateral load control directly from the cab.
The Forklift Side Shifter Attachment is a heavy-duty hydraulic sideshift attachment designed to allow forklift operators to laterally shift loads left or right directly from the cab, eliminating the need to reposition the forklift during pallet placement and retrieval. This carriage-mounted forklift sideshift attachment delivers a lateral shift range of ±100mm, significantly improving load alignment accuracy, operational efficiency, and throughput in warehousing, logistics, and manufacturing environments. Available across multiple class and width configurations — from Class 2A (2–2.5T) to Class 3A (3–4.5T) — with custom sizes available on request to suit specific operational requirements.
Core Selling Points
- Compact Integrated Design: Integrates the cylinder and sideshift frame into a single component, saving space and maximizing the operator's forward sightline for enhanced safety.
- Balanced Lateral Movement: The double-headed rod cylinder design ensures equal thrust force and travel speed on both the left and right sides of the carriage under full load.
- Smooth & Durable Operation: Lower bearing assemblies are manufactured from wear-resistant nylon material, minimizing friction for long-term reliability.
- Easy Installation: Connects directly to the standard fork carriage and is supplied pre-assembled, allowing for fast mounting without specialist equipment.
Specifications
| Type | Class | Dimension (W×D×H)/mm | Amount of Side Shifter /mm | Operating Pressure /MPa | Hydraulic Flow /LPM | Weight /kg | Suit Forklift /T |
|---|---|---|---|---|---|---|---|
| F-CYQ2A20-1040 | 2A | 1040×107×640 | ±100 | 16 | 60 | 58 | 2-2.5 |
| F-CYQ3A30-1100 | 3A | 1100×107×640 | ±100 | 16 | 60 | 73 | 3-3.5 |
| F-CYQ3A30-1500 | 3A | 1500×107×640 | ±100 | 16 | 60 | 91 | 3-3.5 |
| F-CYQ3A30-1600 | 3A | 1600×107×640 | ±100 | 16 | 60 | 97 | 3-3.5 |
| F-CYQ3A40-1350 | 3A | 1350×107×715 | ±100 | 16 | 60 | 176 | 4-4.5 |
Technical Drawing
⚠️ Safety & Compatibility Warnings
- Load De-rating: The addition of this sideshift attachment alters the center of gravity and reduces the effective lifting capacity of the host forklift. Always refer to the derated capacity plate on your forklift before operation.
- Hydraulic Requirements: This is a hydraulic attachment requiring correct hydraulic circuit connections. Verify your forklift's operating pressure (16 MPa) and hydraulic flow rate (60 LPM) are compatible prior to purchase.
- Mounting Compatibility: Ensure your forklift carriage matches the specified ISO Class (Class 2A for 2-2.5T or Class 3A for 3-4.5T) as indicated in the specifications table.
- Installation & Retention: Must be secured correctly using designated retaining methods. Do not operate without securing the attachment properly to the fork carriage.
