LANDYINDUS Heavy-Duty Container Loading Ramp | 8,000kg SWL | Triple Fork Pockets — Side & Front | Chain & D-Shackle Included | 5mm Steel | Forklift, Pallet Truck & Heavy Equipment | Shipping Container, Port & Construction | F-CRN8

LANDYINDUS F-CRN8 Heavy-Duty Container Loading Ramp | 8,000kg SWL — Highest in Series | Triple Fork Pockets (Side & Front) — Maximum Repositioning Flexibility | Chain & D-Shackle Included | 5mm High-Strength Steel | Forklift, Pallet Truck & Heavy Equipment | Shipping Container, Port & Construction Yard

The LANDYINDUS F-CRN8 is a professional-grade steel container loading ramp delivering an 8,000kg SWL — the highest capacity in the LANDYINDUS container ramp series — engineered for safe, efficient, high-capacity loading and unloading of shipping containers using forklifts, pallet trucks, and heavy material handling equipment. Designed for warehouses, logistics hubs, distribution centres, construction yards, and port facilities where maximum load capacity and operational reliability are non-negotiable.

8,000kg SWL — Highest Capacity Container Ramp in the Series

With an 8,000kg SWL, the F-CRN8 supports 1,500kg more than the 6,500kg models (F-CRN65, F-FCR65, F-SDCR65) and 2,000kg more than the 6,000kg models. This capacity is critical for operations involving fully loaded heavy forklifts (typically 3–5 tonne class with load), heavy machinery staging, and high-density pallet loads where combined equipment and load weight can approach or exceed 6,500kg.

Triple Fork Pockets — Side & Front, Maximum Repositioning Flexibility

The F-CRN8 features triple forklift fork pockets — positioned at both sides and the front — giving operators three approach angles for repositioning. This three-point fork pocket layout provides maximum flexibility when aligning the ramp to different container heights and dock configurations:

• Side pockets (165×75mm, 485mm centres): for repositioning in tight lateral spaces where a front approach is blocked
• Front pocket: for direct forward repositioning — the most natural forklift approach direction when moving the ramp between containers

Most competitor ramps offer only side pockets or only a front pocket — the triple pocket layout of the F-CRN8 ensures a repositioning approach is always available regardless of site constraints.

Chain & D-Shackle Included — Secure Anchoring Throughout Loading Cycle

Every F-CRN8 is supplied complete with a heavy-duty chain and D-shackle for secure anchoring to the container during loading and unloading operations. This integrated securing system prevents ramp movement under dynamic forklift loads — particularly important at 8,000kg SWL where the dynamic forces from a heavily loaded forklift crossing the ramp are substantially higher than at lower capacity ratings.

Complete Container Ramp Series — F-CRN8 at Maximum Capacity

One-Piece Welded Construction | 5mm Plate | 2,200mm Width

The robust one-piece welded construction eliminates weak points found in multi-section ramp designs, ensuring consistent load-bearing performance across thousands of operational cycles without deformation or fatigue. The 2,200mm platform width accommodates standard forklift tine spans and wide-load pallets, ensuring compatibility with the full range of common material handling equipment in modern logistics and industrial operations.

Smooth Sloped Entry Profile — Minimises Load Shock & Cargo Damage Risk

The sloped entry profile creates a smooth, gradual transition from ground level to container floor, minimising load shock and reducing the risk of cargo damage or forklift tip during entry. At 8,000kg SWL, the forces involved in a loaded forklift crossing the ramp threshold are substantial — a smooth gradient transition is critical to maintaining load stability and preventing sudden weight transfer that could destabilise the ramp or the load.

Applications

• Port facilities & freight terminals — highest SWL for heavy container operations
• Heavy machinery staging — construction yards, equipment hire depots
• Distribution centres — high-density pallet loading, maximum capacity operations
• Warehouses — heavy forklift access, high-cycle loading
• Industrial yards — bulk material, heavy equipment, multi-container operations

Key Features

• 8,000kg SWL — highest capacity in the LANDYINDUS container ramp series
• Triple fork pockets (side & front, 165×75mm, 485mm centres) — three repositioning approach angles
• Chain & D-shackle included — secure anchoring, dynamic load protection
• One-piece welded steel — no joint failure points, high-cycle durability
• 5mm high-strength structural steel | 2,200mm width
• Smooth sloped entry — load shock minimised, stable forklift crossing
• 258kg | 1,700×2,200×160mm

Specifications

Technical Drawing
