LANDYINDUS Heavy Duty Excavator Digging Bucket | High Capacity | CAT, Komatsu & Sany OEM Brackets | 1–25T | 305–1,372mm Width | 0.02–0.94m³ | 5mm & 10mm Main Plate | 42 Standard Configurations | Custom Sizes Available
The LANDYINDUS Heavy Duty Excavator Digging Bucket series delivers exceptional performance across a wide range of light to medium consistency ground conditions — including soil, loam, non-compacted sand, gravel, and dry clay. Designed with a high-capacity volume configuration, it maximizes material intake per cycle, significantly improving job site productivity and reducing overall cycle times. With 42 standard configurations spanning 1T to 25T excavators and OEM bracket fitment for CAT, Komatsu, and Sany, there is a compatible bucket ready for your machine.
OEM Bracket Fitment — CAT, Komatsu & Sany, No Adapter Modifications Required
The reinforced bracket design ensures precise, secure fitment across a broad range of OEM excavator models, including Caterpillar (CAT), Komatsu, Sany, and other leading brands in the 1T to 25T class — eliminating costly adapter modifications and reducing downtime on site. Technical drawings are available for verification before purchase, giving procurement teams the confidence to specify with accuracy.
Select Your Excavator Brand and Weight Class
Komatsu PC35 — 2–3.5T | 5mm Plate
| Model |
Width (mm) |
Dimensions W×D×H (mm) |
Volume (m³) |
Weight (kg) |
| ME-LS1705 |
305 |
305×655×780 |
0.03 |
74 |
| ME-LS1706 |
406 |
406×664×780 |
0.05 |
92 |
| ME-LS1707 |
457 |
457×664×780 |
0.05 |
99 |
| ME-LS1708 |
610 |
610×664×780 |
0.06 |
123 |
| ME-LS1709 |
762 |
762×664×780 |
0.08 |
145 |
CAT 302 — 1–2T | 5mm Plate
| Model |
Width (mm) |
Dimensions W×D×H (mm) |
Volume (m³) |
Weight (kg) |
| ME-PD25466 |
305 |
305×638×634 |
0.02 |
53 |
| ME-PD25463 |
406 |
406×638×634 |
0.03 |
66 |
| ME-PD25459 |
457 |
457×638×634 |
0.03 |
71 |
| ME-PD25453 |
762 |
762×638×634 |
0.05 |
105 |
CAT 304CR — 4–6T | 5mm Plate
| Model |
Width (mm) |
Dimensions W×D×H (mm) |
Volume (m³) |
Weight (kg) |
| E-PD24164 |
406 |
406×658×875 |
0.06 |
105 |
| E-PD20095 |
610 |
610×658×875 |
0.08 |
137 |
| E-PD24165 |
762 |
762×658×875 |
0.10 |
159 |
CAT 315 — 16–18T | 10mm Plate
| Model |
Width (mm) |
Dimensions W×D×H (mm) |
Volume (m³) |
Weight (kg) |
| E-PD26785 |
610 |
610×1,268×1,458 |
0.34 |
537 |
| E-PD26784 |
762 |
762×1,268×1,458 |
0.44 |
608 |
| E-PD26780 |
1,219 |
1,219×1,268×1,458 |
0.74 |
803 |
CAT 320 — 20–25T | 10mm Plate
| Model |
Width (mm) |
Dimensions W×D×H (mm) |
Volume (m³) |
Weight (kg) |
| E-PD13002 |
610 |
610×1,385×1,540 |
0.37 |
670 |
| E-PD13003 |
762 |
762×1,385×1,540 |
0.48 |
752 |
| E-PD13004 |
914 |
914×1,385×1,540 |
0.60 |
835 |
| E-PD13005 |
1,067 |
1,067×1,385×1,540 |
0.71 |
901 |
| E-PD13006 |
1,219 |
1,219×1,385×1,540 |
0.83 |
955 |
| E-PD13007 |
1,372 |
1,372×1,385×1,540 |
0.94 |
1,043 |
Sany SY16 — 1–2T | 5mm Plate
| Model |
Width (mm) |
Dimensions W×D×H (mm) |
Volume (m³) |
Weight (kg) |
| ME-FL12725-1 |
305 |
305×643×515 |
0.02 |
53 |
| ME-FL12722-1 |
457 |
457×643×515 |
0.03 |
70 |
Sany SY26 — 2–3.5T | 5mm Plate
| Model |
Width (mm) |
Dimensions W×D×H (mm) |
Volume (m³) |
Weight (kg) |
| ME-FL14768-1A |
305 |
305×645×544 |
0.02 |
58 |
| ME-FL14762-1A |
457 |
457×645×544 |
0.03 |
77 |
| ME-FL14759-1A |
610 |
610×645×544 |
0.04 |
86 |
Sany SY35 — 4–6T | 5mm Plate
| Model |
Width (mm) |
Dimensions W×D×H (mm) |
Volume (m³) |
Weight (kg) |
| E-FL12983-1 |
305 |
305×721×525 |
0.02 |
55 |
| E-FL12980-1 |
457 |
457×721×525 |
0.03 |
72 |
| E-FL12977-1 |
610 |
610×721×525 |
0.04 |
93 |
| E-FL12974-1 |
762 |
762×721×525 |
0.05 |
108 |
CAT 308D — 6–8T | 10mm Plate
| Model |
Width (mm) |
Dimensions W×D×H (mm) |
Volume (m³) |
Weight (kg) |
| E-FL12231 |
457 |
457×1,108×917 |
0.03 |
186 |
| E-FL12230 |
610 |
610×1,108×917 |
0.04 |
228 |
| E-FL12229 |
762 |
762×1,108×917 |
0.05 |
265 |
| E-FL12225 |
914 |
914×1,108×917 |
0.06 |
304 |
Sany SY50 — 6–8T | 5mm Plate
| Model |
Width (mm) |
Dimensions W×D×H (mm) |
Volume (m³) |
Weight (kg) |
| E-FL14787-1 |
305 |
305×930×759 |
0.02 |
91 |
| E-FL14784-1 |
457 |
457×930×759 |
0.03 |
117 |
Sany SY60 — 10–14T | 10mm Plate
| Model |
Width (mm) |
Dimensions W×D×H (mm) |
Volume (m³) |
Weight (kg) |
| E-FL14930-1 |
457 |
457×1,186×940 |
0.03 |
208 |
| E-FL14927-1 |
610 |
610×1,186×940 |
0.04 |
253 |
| E-FL14917-1 |
914 |
914×1,186×940 |
0.06 |
339 |
Sany SY75 — 16–18T | 10mm Plate
| Model |
Width (mm) |
Dimensions W×D×H (mm) |
Volume (m³) |
Weight (kg) |
| E-FL12346 |
457 |
457×1,108×923 |
0.03 |
190 |
| E-FL12345 |
610 |
610×1,108×923 |
0.04 |
231 |
| E-FL12344 |
762 |
762×1,108×923 |
0.05 |
269 |
| E-FL12338 |
914 |
914×1,108×923 |
0.06 |
310 |
Plate Thickness by Excavator Class
| Excavator Class |
Main Plate |
Rationale |
| 1–8T (mini to compact) |
5mm |
Lower digging forces, weight-sensitive |
| 6–25T (mid to large) |
10mm |
Higher structural loads, harder ground conditions |
Key Features
- 42 standard configurations — 1T to 25T, 305mm to 1,372mm, 0.02 to 0.94m³
- OEM bracket fitment — CAT 302/304CR/308D/315/320, Komatsu PC35, Sany SY16/26/35/50/60/75
- No adapter modifications required — direct fit, reduced downtime
- 5mm plate (1–8T) & 10mm plate (6–25T) — matched to excavator weight class
- High-capacity volume — maximise material intake per cycle
- Soil, loam, sand, gravel, dry clay — light to medium ground conditions
- Technical drawings available — verify before purchase
- Custom dimensions available on request
⚠️ Compatibility Note: Specify your excavator brand, model, and weight class when ordering. Technical drawings available on request. Custom widths and bracket configurations available — contact us for project-specific requirements.
Technical Drawing:
