LANDYINDUS Heavy Duty Hydraulic Silage Shear Grab | Third Circuit | Euro & SMS Bracket Tractor

LANDYINDUS T-170SS Heavy Duty Hydraulic Silage Shear Grab | Third Circuit | Euro & SMS | 0.98m³ | 602kg SWL

The LANDYINDUS T-170SS Heavy Duty Silage Shear Grab is a professional-grade hydraulic tractor attachment engineered for efficient, clean, and low-force silage cutting and handling in demanding farm and agricultural environments. Requiring a third hydraulic circuit and powered by two heavy-duty hydraulic cylinders, the T-170SS delivers ample clamping and cutting force to tackle even the most compacted and dense silage faces with ease. Available with both Euro and SMS bracket options, it is compatible with a wide range of tractor front loaders for farms and agricultural contractors running varied equipment fleets.

Hardened Serrated Front Knife & Plain Side Knives — Clean Circular Cuts, Minimal Resistance

At the heart of the T-170SS is a precision cutting system combining a hardened serrated front knife with plain side knives, working together to achieve clean circular cuts through silage with minimal resistance. The rounded front profile guides the attachment into the silage face smoothly, reducing the force required to initiate the cut and minimising disturbance to the surrounding stack. This combination of serrated and plain knife geometry ensures a consistently clean cut face — critical for maintaining silage quality and reducing spoilage at the cut edge, a key concern for livestock farmers managing large silage pits.

0.98m³ Capacity | 730mm Opening Range | SWL 602kg — High-Volume Per Cycle

With a safe working load of 602kg, an opening range of 730mm, and a capacity of 0.98m³, the T-170SS moves large volumes of silage efficiently in each cycle — significantly reducing the number of passes required during feeding or pit management operations. The generous capacity combined with the clean-cut knife system makes the T-170SS one of the highest-productivity silage handling attachments in its class.

11 Bottom Tines + 2 Side Tines — Removable in Tapered Sleeves for Fast Field Maintenance

The 11 bottom tines (φ36×820mm) and 2 side tines (φ36×810mm) are fitted into tapered sleeves and are fully removable, making field maintenance and tine replacement straightforward even under heavy daily use. Individual tine replacement eliminates the need to remove or replace the full grab assembly — minimising downtime during busy feeding seasons and reducing the long-term cost of consumable components.

16 MPa / 60 LPM | Two Hydraulic Cylinders — Consistent High-Performance Across Extended Sessions

Operating at 16 MPa with a hydraulic flow requirement of 60 LPM, the T-170SS delivers consistent, high-performance cutting and clamping across extended working sessions. Two heavy-duty hydraulic cylinders provide the clamping force required to handle compacted silage faces, dense bales, and high-density forage material without loss of grip or cutting performance under continuous load.

Key Features

• Hardened serrated front knife + plain side knives — clean circular cuts, minimal disturbance
• Rounded front profile — low-force entry into compacted silage faces
• Clean cut face — maintains silage quality & reduces spoilage at cut edge
• 0.98m³ capacity | 730mm opening | SWL 602kg — high-volume per cycle
• 11 bottom tines + 2 side tines — removable in tapered sleeves, individual field replacement
• Two hydraulic cylinders | third circuit | 16MPa / 60LPM
• Euro & SMS bracket — compatible with a wide range of tractor front loaders
• 1,780×950×920mm | 569–571kg | suited to farms & agricultural contractors

Technical Drawing:

Specifications
