LANDYINDUS Heavy-Duty Skid Steer Disc Harrow Attachment | 96" 22-Blade Tilling & Weed Control Universal Skid Steers Quick Attach

LANDYINDUS Heavy-Duty Skid Steer Disc Harrow Attachment | 96" 22-Blade Tilling & Weed Control Universal Skid Steers Quick Attach

Break compacted soil. Chop weeds. Incorporate residue. One pass. The LANDYINDUS 96" Skid Steer Disc Harrow Attachment is a heavy-duty tilling solution designed to break up compacted soil, chop down unwanted weeds, and incorporate crop residues back into the ground with maximum efficiency. Spanning 2340mm (96") in working width, this skid steer disc harrow is built for large-scale field preparation — an ideal choice for farmers, landscapers, and land clearing contractors who need serious ground-working performance from their skid steer loader.

Dual-Gang 22-Blade Configuration — Primary Tillage & Soil Finishing in One Pass

This disc harrow features a dual-gang configuration with 22 total blades:

• 12 smooth concave disc blades at 610mm diameter — lift and loosen soil as they cut, improving aeration and seedbed preparation
• 10 notched disc blades at 560mm diameter — aggressively slice through tough crop residues, roots, and compacted clods that smooth discs alone cannot break down

The combination of smooth concave and notched blades gives the S-DH2440 the versatility to handle both primary tillage and secondary soil finishing in a single pass — reducing the number of field passes required and cutting total field preparation time.

Concave Disc Design — Lifts & Loosens Soil During Cutting

The concave disc geometry is engineered to do more than cut — as each disc rotates through the soil, the concave profile lifts and turns the soil upward, breaking up compaction layers and creating the loose, aerated seedbed structure that promotes germination and root development. This soil-lifting action is what separates a quality disc harrow from a flat-blade alternative on heavy or clay-dominant soils.

666kg Heavy-Duty Steel Frame — Built for Repeated Large-Scale Field Work

Weighing 666kg and built from high-strength steel throughout, the S-DH2440 is engineered to withstand the demands of repeated heavy-duty field work without bending or wearing prematurely. The structural mass also adds downforce on the disc gangs — improving soil penetration depth on hard or dry ground without requiring additional ballast.

Universal Skid Steer Mount — Fast Attachment & Detachment Between Jobs

The skid steer mounting system is compatible with most standard universal skid steer loaders, allowing for fast attachment and detachment between jobs — no custom fabrication or additional adapters required. Whether you are preparing a seedbed, managing post-harvest residue, or reclaiming overgrown land, the LANDYINDUS 96" disc harrow delivers the cutting power and durability to get the field ready.

Key Features

• 96" (2340mm) working width for large-scale field preparation
• Dual-gang 22-blade configuration: 12 smooth concave (610mm) + 10 notched (560mm)
• Concave disc design lifts and loosens soil during cutting for improved aeration
• Notched blades aggressively slice crop residues, roots & compacted clods
• Primary tillage and secondary soil finishing in a single pass
• 666kg high-strength steel frame — structural mass adds natural downforce on hard ground
• Universal skid steer mount — no adapters or modifications required
• Ideal for seedbed preparation, post-harvest residue management & land reclamation

Technical Drawing:

Specifications
