LANDYINDUS Heavy Duty Skid Steer Rock Bucket Grapple with Teeth | 60 72 82 Inch | MP1140

LANDYINDUS Heavy Duty Skid Steer Rock Bucket Grapple with Teeth | 60 / 72 / 82 Inch | MP1140 Universal Quick Attach

The LANDYINDUS Skid Steer Rock Bucket Grapple with Teeth is engineered for operators who need maximum gripping power and penetration performance when handling rock, demolition debris, concrete rubble, logs, and dense brush. Unlike standard tine-style grapples, this attachment features 12mm thick teeth that bite into hard, irregular surfaces with far greater force — making it the right choice for heavy rock handling, demolition site cleanup, and any application where a conventional grapple struggles to maintain a secure hold.

12mm Toothed Clamp Arms — Penetrates Debris Piles, Locks onto Uneven Rock, Prevents Load Shift

The 12mm toothed clamp arms are designed to penetrate debris piles and lock onto uneven rock surfaces — preventing load shift during the carry cycle and reducing the risk of material spillage on site. The bucket and grapple combination uses the rock bucket as the base sifting and loading platform while the hydraulic grapple clamp locks material in place during lifting and transport, delivering a secure hold that standard tine grapples cannot match on irregular, hard surfaces.

1,160mm Full Opening Range — Accommodates Exceptionally Large & Bulky Loads

With a full opening range of 1,160mm, this attachment can accommodate exceptionally large and bulky loads that smaller grapples simply cannot grip. Available in three widths — 60", 72", and 82" — with two clamp configurations: the 60" model features a single clamp arm for lighter, more manoeuvrable operation in tighter work areas, while the 72" and 82" models are equipped with dual clamp arms for greater clamping force and load stability in high-volume rock handling and heavy demolition cleanup.

16 MPa | 60 LPM — Direct Integration with Standard Skid Steer Hydraulic Circuits

All models operate at up to 16 MPa with a recommended hydraulic flow of 60 LPM, integrating directly with standard skid steer hydraulic circuits without modification. Compatible with most skid steer loaders and compact track loaders equipped with a universal MP1140 quick attach plate. Working weights range from 377kg to 526kg depending on model — reflecting the heavy-duty toothed construction that makes this the strongest and most capable rock grapple in the LANDYINDUS lineup.

Key Features

• 12mm thick teeth — penetrates debris piles & locks onto uneven rock surfaces
• 1,160mm full opening range — accommodates exceptionally large & bulky loads
• 60" single clamp — lighter, more manoeuvrable for tighter work areas
• 72" & 82" dual clamp — greater clamping force for high-volume rock & demolition
• 16 MPa | 60 LPM — direct integration with standard skid steer hydraulic circuits
• Universal MP1140 quick attach — most skid steer loaders & compact track loaders
• 377–526kg working weight — heavy-duty toothed construction for maximum grip strength
• Suited to rock removal, demolition debris, concrete rubble, logs & dense brush

Technical Drawing:

Specifications
