LANDYINDUS Heavy Duty Skid Steer Root Grapple Attachment | 59 62 66 68 72 78 84 Inch | Dual Cylinder | MP1140

LANDYINDUS Heavy Duty Skid Steer Root Grapple Attachment | 59 / 62 / 66 / 68 / 72 / 78 / 84 Inch | Dual Cylinder | MP1140 Universal Quick Attach

The LANDYINDUS Heavy Duty Skid Steer Root Grapple is designed for operators who need a reliable, high-capacity grapple for land clearing, brush removal, root extraction, rock handling, log carrying, and general job site cleanup. Combining the structural strength of a heavy-duty frame with dual independent hydraulic cylinders, this attachment delivers consistent gripping force across a wide range of materials and load sizes — built for contractors, landscapers, and farm operators who run their machines hard.

Dual Independent Hydraulic Cylinders — Balanced Pressure, Secure Grip on Asymmetric & Irregular Loads

The dual cylinder configuration drives both grapple arms with balanced hydraulic pressure, ensuring a secure and even grip even when handling asymmetric or irregularly shaped loads. The dual cylinder design provides the clamping force needed for root grapple work where single-cylinder attachments often fall short — particularly when extracting embedded roots or gripping dense brush bundles. Every pivot point is fitted with grease fittings for straightforward maintenance.

10mm Tines | 1,050mm Full Opening Range — Root Balls, Brush Piles & Oversized Debris in One Pass

The grapple features 10mm thick tines with a full opening range of 1,050mm, giving operators the reach and bite needed to grab large root balls, brush piles, and oversized debris in a single pass. The overall frame is engineered to maintain structural integrity under repeated heavy-cycle use across land clearing, stump pulling, fence line clearing, rock pile moving, and post-demolition cleanup.

16 MPa | 60 LPM | 320–390kg — Seven Widths from 59" to 84" for Every Machine & Application

The hydraulic system operates at up to 16 MPa with a recommended flow of 60 LPM, compatible with the hydraulic circuits of most standard skid steer loaders and compact track loaders without additional modifications. Available in seven widths — 59", 62", 66", 68", 72", 78", and 84" — with working weights from 320kg to 390kg depending on model. Fits most machines equipped with a universal MP1140 quick attach plate.

Key Features

• Dual independent hydraulic cylinders — balanced pressure, secure grip on asymmetric loads
• 10mm thick tines — root balls, brush piles & oversized debris in one pass
• 1,050mm full opening range — largest opening in the LANDYINDUS grapple lineup
• Grease fittings at all pivot points — straightforward maintenance, extended service life
• Heavy-duty frame — structural integrity under repeated heavy-cycle use
• 16 MPa | 60 LPM — standard skid steer hydraulic circuits, no modifications
• Seven widths: 59", 62", 66", 68", 72", 78", 84" — 320–390kg
• Universal MP1140 quick attach — most skid steer loaders & compact track loaders

Technical Drawing:

Specifications
