LANDYINDUS Heavy-Duty Skid Steer Root Grapple Rake Attachment | 64" & 72" Forestry Grapple Brush & Land Clearing Quick Attach

LANDYINDUS Heavy-Duty Skid Steer Root Grapple Rake Attachment | 64" & 72" Forestry Grapple Brush & Land Clearing Quick Attach

Grab more. Move more. Clear faster. The LANDYINDUS Skid Steer Root Grapple Rake is a heavy-duty forestry attachment purpose-built for picking up and moving brush, tree tops, large bundles of branches, and woody debris across forestry, land clearing, and site cleanup applications. Available in 64" (1,130kg SWL) and 72" (1,315kg SWL), this skid steer forestry grapple gives operators the jaw capacity and structural strength to handle high-volume brush and timber material that standard grapple buckets struggle to contain.

0 to 1,090mm Full-Range Jaw Opening — Flat Scrape to Wide Engulf in One Attachment

The standout feature of the S-RGR series is its full-range jaw opening of 0 to 1,090mm:

• Closed (0mm): closes completely flat for scraping and raking loose brush off the ground surface
• Fully open (1,090mm): wide span to engulf large tree tops and bulky branch bundles in a single grab

No other attachment position needed. The full jaw range means the LANDYINDUS root grapple rake handles both fine ground-level brush raking and large-volume tree top grabbing — in the same attachment, on the same machine, without switching tools.

Rake-Style Tine Design — Fine Debris Falls Through, Large Material Stays In

The rake-style tine design lets fine debris, soil, and small material fall through the tines while retaining larger branches, tree tops, and woody debris for efficient sorting and transport. The result: cleaner material loads, less soil contamination in brush piles, and faster site cleanup with fewer secondary passes to sort material.

12mm Main Plate — Withstands Twisting & Impact Loads from Aggressive Forestry Work

The 12mm main plate thickness provides the structural rigidity needed to withstand the twisting and impact loads that come with aggressive forestry work. When the grapple closes on a dense tangle of branches or a large tree top, the 12mm shell holds its geometry under the torsional stress — keeping the jaw mechanism aligned and the tines parallel through repeated high-force grab cycles.

2 Width Options — 64" & 72" for High-Volume Forestry & Land Clearing

Operating at 16 MPa with 60 LPM hydraulic flow, the S-RGR series integrates directly with most standard universal skid steer loaders and compact track loaders. Both models install quickly and work hard from the first grab:

• 64" (S-RGR1630): 1,130kg SWL, 404kg — agile forestry grapple for tighter site conditions
• 72" (S-RGR1830): 1,315kg SWL, 429kg — wider jaw for higher-volume brush and tree top handling

Key Features

• Full-range jaw opening: 0 to 1,090mm — flat scrape to wide engulf in one attachment
• Rake-style tines — fine debris falls through, large material retained for efficient transport
• 12mm main plate for twisting and impact load resistance in aggressive forestry work
• Available in 64" (1,130kg SWL) and 72" (1,315kg SWL)
• 16 MPa / 60 LPM hydraulic system
• Universal quick attach — compatible with most skid steer loaders and compact track loaders
• Ideal for brush clearing, tree top removal, storm debris cleanup & post-harvest land clearing

Specifications
