LANDYINDUS T-HLB Heavy Duty Wheel Loader Leveler Bucket | 87" to 118" (2,200–3,000mm) | 1.80 to 2.40m³ | 10mm Main Plate | Extra High Strength Steel Wear Areas | Big BM Quick Attach | Volvo L35-Class and Larger

The LANDYINDUS T-HLB Heavy Duty Wheel Loader Leveler Bucket is a professional-grade grading attachment engineered for mid-size to large wheel loaders, available in four widths from 2,200mm to 3,000mm (87 to 118 inches) to match the working requirements of different machine classes and job-site scales. With a bucket capacity ranging from 1.80 to 2.40 cubic meters, it delivers the volume and coverage needed for efficient material spreading, site leveling, and grading operations across construction, road maintenance, and earthmoving applications.

10mm Main Plate + Extra High Strength Steel Wear Areas — Flat Consistent Grading Profile Under Load, Long Service Life

Built from structural steel throughout, with wear-critical contact areas reinforced in extra high strength steel, this leveler bucket is designed to withstand the abrasive conditions of repeated grading cycles without accelerated wear to the cutting edge or base plate. The 10mm main plate thickness provides the rigidity needed to maintain a flat, consistent grading profile under load — a key factor in achieving accurate finish grades on road bases, parking areas, and building pads. The result is a bucket that holds its geometry and performance over a long service life, reducing replacement and downtime costs.

1,420mm Deep Profile | 1.80 to 2.40m³ — High-Volume Coverage for Large-Scale Site Grading

The 1,420mm deep bucket profile delivers high-volume material capacity across all four width variants, enabling efficient spreading and leveling of large quantities of topsoil, road base, gravel, and fill material in fewer passes. The 2.40m³ capacity on the 3,000mm model makes it the highest-volume leveler bucket in the LANDYINDUS lineup, suited to the largest wheel loader classes and widest grading tasks.

Big BM Quick Attach — Volvo L35-Class and Larger, Fast Secure Coupling, No Adapters

Fitted with a Big BM quick-attach bracket as standard, this wheel loader leveler bucket is compatible with Volvo L35-class machines and larger, as well as other mid-size and large wheel loaders running Big BM coupler systems. Fast, secure coupling without adapters or custom mounting hardware.

Complete Leveling Bucket Range — Light Duty to Heavy Duty

Key Features

• 10mm main plate + extra high strength steel wear areas — long service life, no geometry loss
• 1,420mm deep profile — high-volume material capacity per pass
• Four widths: 87" to 118" (2,200–3,000mm) — match to machine class and task scale
• 1.80 to 2.40m³ capacity — highest-volume leveler in the LANDYINDUS lineup
• Big BM quick attach — Volvo L35-class and larger, no adapters
• 665kg (87") to 950kg (118") — mid-size to large wheel loader systems
• Road sub-base, topsoil spreading, parking areas, building pads and large yard leveling

Technical Drawing:

Specifications
