LANDYINDUS Heavy Duty Wheelie Bin Tipper 250kg 240L/120L/80L Compatible WS-BT Series
Couldn't load pickup availability
Got questions?
Feel free to get in touch
Ask an expert!
Product Overview
Eliminate manual heavy lifting and reduce workplace injury risks with the LANDYINDUS Heavy Duty Wheelie Bin Tipper, built for effortless 250kg single-operator waste handling.
The LANDYINDUS Heavy Duty Wheelie Bin Tipper is engineered for efficient, single-operator waste bin emptying in industrial, commercial, and municipal environments. Designed to handle bins up to 250kg SWL, it eliminates the need for manual lifting, significantly reducing labor costs and workplace injury risks. The standard model features a bracket designed for 240L wheeled bins, with an optional spring-loaded bracket available to accommodate 80L, 120L, and 140L bins, allowing one machine to handle multiple bin sizes across your site.
Core Selling Points
- Heavy-Duty 250kg Capacity: Robust steel construction engineered to lift and dump bins up to 250kg SWL reliably under intensive daily use.
- Flexible Bin Compatibility: Standard cradle designed for 240L wheelie bins, with optional spring-loaded adapters for 80L, 120L, and 140L containers.
- Multiple Dump Heights: Available in 4 dump heights (1600mm, 1800mm, 2000mm, and 2200mm) to match bulk waste skips, hoppers, and compactor inlets.
- Single-Operator Efficiency: Streamlined controls allow one operator to safely complete the full lift and tip cycle with minimal training and zero physical strain.
Specifications
| Type | SWL / kg | Dimension (L×W×H) / mm | Dumping Height (Hd) / mm | Weight / kg |
|---|---|---|---|---|
| WS-BT16 | 250 | 1293×1351×2783 | 1600 | 379 |
| WS-BT18 | 250 | 1293×1351×2983 | 1800 | 395 |
| WS-BT20 | 250 | 1293×1351×3183 | 2000 | 410 |
| WS-BT22 | 250 | 1293×1351×3383 | 2200 | 435 |
Technical Drawing
⚠️ Safety & Compatibility Warnings
- Overhead Clearance: Verify adequate vertical ceiling clearance prior to operation. Overall mast height reaches up to 3383mm at maximum extension on the WS-BT22 model.
- Safe Working Load (SWL): Do not exceed the rated 250kg maximum load limit. Always inspect bin structural integrity before loading into the cradle.
- Ground Level & Stability: The tipper must be positioned on a firm, level concrete surface during lifting and dumping cycles to prevent lateral tipping hazards.
- Bin Clamping & Lock: Ensure the wheelie bin lip and wheels are fully seated and securely retained in the cradle assembly before activating the lift cycle.
