LANDYINDUS High Tip Bucket | +2.2m Dump Height | 63"-103" | 1.40-2.40m³ | Dual Cylinder Frame | Grain Silage Wood Chip | Euro Quick Attach | T-HTB

LANDYINDUS T-HTB Hydraulic High Tip Bucket | +2.2m Extra Dump Height | 63" to 103" (1,600–2,620mm) | 1.40 to 2.40m³ | Dual Hydraulic Cylinder Frame | Grain, Silage & Wood Chip | Euro Quick Attach | Tractor Front Loader

The LANDYINDUS T-HTB Hydraulic High Tip Bucket is engineered to increase the dump height by 2.2 meters compared to a conventional front loader bucket. Available in six working widths — 63" (1,600mm), 71" (1,800mm), 79" (2,010mm), 87" (2,210mm), 95" (2,410mm), and 103" (2,620mm) — with volumes ranging from 1.40 to 2.40 cubic meters, this high dump bucket allows operators to load directly into tall trailers, elevated hoppers, storage bins, and grain silos that a standard tractor bucket cannot reach without additional handling equipment.

+2.2m Extra Dump Height — Eliminates Ramps, Elevated Platforms and Intermediate Transfer Steps

The extended dump height capability addresses one of the most common productivity bottlenecks in agricultural and bulk material handling operations: the inability of a standard front loader to discharge material at the height required by the receiving container. By adding 2.2 meters of effective dump height through the high tip mechanism, the T-HTB eliminates the need for ramps, elevated loading platforms, or intermediate transfer steps when filling tall trailers and storage structures. This directly reduces the number of handling stages per load cycle and the associated labor and equipment costs.

Dual Hydraulic Cylinder Frame — Even Force Distribution, No Lateral Flex, Stable at Maximum Height Under Full Load

The high tip mechanism is driven by a dual hydraulic cylinder frame that connects the bucket to the front loader mounting interface. The twin-cylinder configuration distributes the extension and retraction forces evenly across the frame, maintaining structural stability and precise bucket control throughout the full range of tip height adjustment. This balanced load distribution prevents the lateral flex and instability that can occur with single-cylinder high tip designs under full bucket load, ensuring consistent, controlled dumping at maximum height even with dense or unevenly distributed material in the bucket.

Six Width Options — 63" to 103" | 1.40 to 2.40m³ | Match to Tractor Lift Capacity and Working Width

The T-HTB range covers six working widths to match different tractor sizes, front loader lift capacities, and working width requirements:

• 63" (1,600mm) — 1.40m³ | 481kg — compact tractor front loaders
• 71" (1,800mm) — 1.51m³ | 514kg — mid-range tractor front loaders
• 79" (2,010mm) — 1.75m³ | 566kg — standard agricultural tractor front loaders
• 87" (2,210mm) — 1.96m³ | 600kg — large agricultural tractor front loaders
• 95" (2,410mm) — 2.18m³ | 635kg — high-capacity agricultural front loaders
• 103" (2,620mm) — 2.40m³ | 669kg — maximum width, large farm and commercial operations

Grain, Silage, Wood Chip, Compost & Grass Seed — Low to Medium Density Bulk Materials

The T-HTB is designed for low to medium density bulk materials including grain, grass seed, wood chips, silage, compost, and similar agricultural and horticultural products where the combination of high dump height and adequate bucket volume delivers the greatest productivity benefit.

T-HTB vs T-VXL vs T-4IN1B — Choosing the Right Bucket

Key Features

• +2.2m extra dump height — tall trailers, hoppers, silos, no ramps or platforms
• Dual hydraulic cylinder frame — even force distribution, no lateral flex at max height
• Six widths: 63" to 103" — 1.40 to 2.40m³, match to tractor lift capacity
• Euro quick attach — wide tractor compatibility, no adapters
• Grain, silage, wood chip, compost and grass seed
• 481kg (63") to 669kg (103") — wide range of front loader systems

Specifications
