LANDYINDUS Hitch Mounted Subsoil Ripper | 2" Receiver | 4 Depth Settings | Reversible Carbon Steel Shank | Shear Bolt Protection | ATV UTV Cat 0 & 1 | T-RPV2

LANDYINDUS T-RPV2 Hitch Mounted Subsoil Ripper V2 | 2" Receiver Hitch | 4 Adjustable Depth Settings | Reversible Carbon Steel Shank | Shear Bolt Machine Protection | ATV, UTV & Cat 0/1 Tractor | 9kg

The LANDYINDUS T-RPV2 Hitch Mounted Ripper V2 is a compact, heavy-duty subsoil ripper designed to attach directly to any standard 2-inch receiver hitch, making it an ideal tool for ATV, UTV, and Category 0 and Category 1 tractor owners who need to break through hard, compacted, or dry soil without investing in large equipment. Whether you are conditioning garden beds, opening trenches for irrigation lines, laying underground wiring, or loosening clay-heavy ground before planting, this single-tine ripper delivers the penetration depth and pulling force needed to get the job done efficiently.

2" Receiver Hitch | 3" Steel Past Pin Hole — Secure, Rattle-Free Connection, No Adapters Required

The shank extends 3 inches past the pin hole to fill the receiver tube securely, eliminating play and ensuring a stable, rattle-free connection during operation. Setup is straightforward — simply slide the unit into your existing 2-inch receiver hitch and pin it in place, with no additional adapters or tools required for most ATV and UTV applications.

4 Adjustable Depth Settings — Dial In Operating Depth to Match Soil Conditions and Task

The ripper features four adjustable depth settings, allowing you to dial in the operating depth based on soil conditions and the task at hand — shallow for garden bed conditioning, deeper for irrigation trenching or clay-layer penetration.

Reversible Carbon Steel Shank — Double the Cutting Edge Life, Flip When One Side Wears

The reversible carbon steel shank is engineered to cut through tough terrain including hard-packed dirt, dry summer soil, and compacted mud layers. When one edge wears down, simply flip the shank to expose a fresh cutting edge, extending the working life of the attachment and reducing long-term maintenance costs. The aggressive tooth geometry ensures consistent soil penetration even in challenging ground conditions.

Shear Bolt Machine Protection — Absorbs Impact on Buried Rocks and Roots Before Damage Reaches Your Hitch

A shear bolt is built into the shank as a protective mechanism for both the ripper and your machine. If the tine strikes a buried rock, root, or other immovable obstruction, the shear bolt absorbs the impact and breaks before damage can transfer to your hitch receiver or vehicle frame. Replacement shear bolts are inexpensive and easy to swap in the field, keeping downtime to a minimum.

T-RPV2 vs 3-Point Hitch Ground Engagement Tools — 2" Receiver vs Cat 1/2 Rear Hitch

Key Features

• 2" receiver hitch — ATV, UTV, Cat 0 & Cat 1 tractor, no adapters
• 3" steel past pin hole — rattle-free, secure connection
• 4 adjustable depth settings — garden beds to deep irrigation trenching
• Reversible carbon steel shank — double cutting edge life, flip when worn
• Shear bolt machine protection — buried rocks and roots, field-replaceable
• 9kg | 430×76×280mm — lightest ground engagement tool in the LANDYINDUS range
• Garden beds, irrigation trenches, underground wiring, clay-heavy ground

Technical Drawing:

Specifications
