LANDYINDUS Hydraulic 180° Rotating Pallet Forks Skid Steer | Class 2A | 1,500kg SWL | Cab-Controlled Rotator | MP1140

LANDYINDUS S-HRB2A15-180°-MP1140 Hydraulic 180° Rotating Pallet Forks Skid Steer | Class 2A | 1,500kg SWL | Cab-Controlled Rotator | MP1140 Universal Quick Attach

The LANDYINDUS S-HRB2A15 Hydraulic 180° Rotating Pallet Forks are a Class 2A skid steer pallet fork attachment that adds full hydraulic rotational capability to standard pallet fork operations, enabling operators to rotate loads up to 180 degrees from the cab without dismounting the machine. Compatible with the MP1140 universal quick-attach interface and rated to a safe working load of 1,500kg (approx. 3,300 lbs), this rotating pallet fork attachment is engineered for material handling applications where load orientation, directional control, and operational flexibility are critical.

180° Hydraulic Rotation — Reorient Loads in Tight Aisles, Compensate for Slope, Tip & Dump — All from the Cab

The 180-degree hydraulic rotation capability solves a range of practical challenges that standard fixed pallet forks cannot address:

• Tight warehouse aisles & confined job sites — reorient a palletised load to match a storage rack, loading dock, or vehicle bed orientation without repositioning the machine
• Sloped or uneven terrain — compensate for ground angle and maintain fork tine level relative to the load, reducing pallet slip or load instability during lifting and transport
• Bulk material tipping & dumping — 180° rotation enables controlled tipping and dumping of container loads directly from the fork frame, eliminating the need for a separate bucket or dumping attachment

16 MPa | 60 LPM — Smooth, Controlled Rotation Under Load, No Pressure Spikes or Jerky Movement

Operating on a hydraulic flow of 60 LPM at up to 16 MPa, the rotation mechanism integrates with the skid steer’s auxiliary hydraulic circuit and delivers smooth, controlled rotation under load without pressure spikes or jerky movement. The Class 2A frame construction provides the structural rigidity needed to maintain a 1,500kg safe working load throughout the full rotation arc — ensuring the attachment performs safely at any rotational angle, not just in the standard forward-facing position.

Reinforced Pivot Points & Hydraulic Cylinder Mounts — Built for the Additional Torsional Stress of Rotational Operation

The heavy-duty frame design is built to withstand the additional torsional stress that rotational operation places on the attachment structure, with reinforced pivot points and hydraulic cylinder mounts engineered for long-term high-cycle use. At 179kg with overall dimensions of 1,240 × 315 × 587mm, the attachment is heavier than fixed-frame alternatives due to the rotator mechanism — offset by the elimination of manual load repositioning steps that would otherwise require additional equipment or operator dismounts.

Class 2A Tines Available on Request — Select Dimensions to Match Load Type & Duty Cycle

Fork tines are available on request in Class 2A specification to complete the attachment configuration, allowing operators to select tine dimensions that match their specific load type and duty cycle requirements.

OEM & Custom Manufacturing Available

LANDYINDUS supports full OEM and custom manufacturing for this rotating pallet fork frame, including rotation angle, SWL rating, tine specification, and interface customisation for dealers and fleet operators with volume sourcing requirements. Contact us to discuss your specifications and request a quote.

Key Features

• 180° hydraulic rotation — reorient loads in tight spaces, compensate for slope, tip & dump
• Cab-controlled rotation — no dismounting, no manual load repositioning
• Class 2A | 1,500kg (3,300 lbs) SWL — maintained throughout full 180° rotation arc
• 16 MPa | 60 LPM — smooth rotation under load, standard auxiliary hydraulics
• Reinforced pivot points & cylinder mounts — long-term high-cycle rotational use
• 1,240×315×587mm | 179kg — compact rotator profile
• Class 2A tines available on request — match dimensions to load type & duty cycle
• MP1140 universal quick attach — most mid-to-large skid steer loaders
• OEM & custom manufacturing available — rotation angle, SWL, tine spec & interface

Technical Drawing:

Specifications
