LANDYINDUS Hydraulic Pallet Fork Frame | 2.5t to 12t | Cab-Controlled | Optional Side Shift | 1,200–2,500mm | Euro, SMS, Z602, Big BM & BM L150/180 | CTJ

SKU: T-2A-1200-2.5T-TJ-EURO

Got questions?

Feel free to get in touch

Ask an expert!

Chat Email +(1) 657-271-9801

LANDYINDUS CTJ Hydraulic Pallet Fork Frame | 2.5t to 12t SWL | Cab-Controlled Hydraulic Fork Positioning | Optional Side Shift | 1,200–2,500mm | Euro, SMS, Z602, Big BM & BM L150/180 | Tractor Front Loader

The LANDYINDUS CTJ Hydraulic Pallet Fork Frame brings full hydraulic fork control to your front loader, eliminating the need for manual repositioning and dramatically improving efficiency on busy job sites. Unlike standard fixed or manually adjustable pallet fork frames, the CTJ uses your tractor’s existing hydraulic system to move and position the forks directly from the cab, allowing operators to handle pallets, bales, and bulk materials with precision and speed without ever leaving the seat.

Cab-Controlled Hydraulic Fork Positioning — No Manual Adjustment, No Leaving the Seat

The hydraulic fork positioning system allows the operator to adjust fork spacing and position directly from the cab using the tractor’s existing hydraulic circuit. This eliminates the repeated dismounting required with manual fork frames — a significant productivity advantage on high-cycle pallet handling operations where fork spacing needs to be adjusted frequently between different load widths.

Optional Side Shift — Lateral Fork Movement for Off-Center Pallets, Tight Racking and Awkward Loads

Side shifting is available as an optional upgrade via an additional oil valve control, adding lateral fork movement that makes it significantly easier to align forks with off-center pallets, tight racking systems, and awkward load positions. This feature is particularly valuable in warehouse and storage environments where precise pallet placement is critical and repeated repositioning of the tractor would otherwise slow down operations considerably.

Four Load Classes — 2.5t to 12t, Compact Farm Tractor to Large Industrial Loader

Class SWL Fork Width Bracket Options Weight Range
2A 2,500kg 1,200mm Euro, SMS, Vila/Valtra, Z602 78–88kg
3A 5,000kg 1,500 & 2,000mm Big BM 165–207kg
4A 8,000kg 1,500, 2,000 & 2,200mm Big BM 198–271kg
4A 12,000kg 1,500, 2,500mm Big BM, BM L150-180 243–446kg

Euro, SMS, Z602, Big BM & BM L150/180 — Wide Loader Compatibility

Bracket compatibility covers Euro, SMS, Trima, Vila/Valtra, Z602, and Big BM, ensuring the CTJ can be fitted to the majority of tractor loader models used across North America and Europe. Fork type and bracket configuration are specified at the time of order, allowing each unit to be tailored precisely to your machine and application.

⚠️ Important: Class 3A (5,000kg), Class 4A (8,000kg) and Class 4A (12,000kg) models are designed for large loaders with Big BM or BM L150/180 coupler systems with the structural capacity to support the full rated load. Always verify your tractor loader’s rated lift capacity before selecting a CTJ class. Never exceed the rated SWL.

CTJ Hydraulic vs T-Series Fixed vs T-SFF Floating — Which Pallet Fork Frame?

Feature T-SFF Floating T-Series Fixed CTJ Hydraulic (This)
Fork adjustment Fixed (self-levels) Manual Hydraulic — cab-controlled
Side shift No No Optional — oil valve add-on
SWL range 2,000kg 1,500–8,000kg 2,500–12,000kg
Terrain adapt Self-leveling Fixed Fixed (hydraulic positioning)
Best for Uneven terrain Standard pallet work High-cycle, warehouse, precision placement

Key Features

  • Cab-controlled hydraulic fork positioning — no manual adjustment, no dismounting
  • Optional side shift — oil valve add-on, lateral movement for tight racking
  • 2.5t to 12t SWL — Class 2A, 3A & 4A
  • 1,200 to 2,500mm fork width — standard to wide-format industrial loads
  • Euro, SMS, Vila/Valtra, Z602, Big BM & BM L150/180
  • Fork type and bracket specified at order — tailored to machine and application
  • 14 SKUs covering compact farm tractors to large industrial loaders

Technical Drawing:

Specifications

Model Class SWL (kg) Width (mm) Mount Weight (kg)
T-2A-1200-2.5T-TJ-EURO 2A 2,500 1,200 EURO 78
T-2A-1200-2.5T-TJ-SMS-C 2A 2,500 1,200 SMS 88
T-2A-1200-2.5T-TJ-Vila/Valtra 2A 2,500 1,200 Vila/Valtra 78
T-2A-1200-2.5T-TJ-Z602 2A 2,500 1,200 Z602 82
T-3A-1500-5T-TJ-BIG BM 3A 5,000 1,500 BIG BM 165
T-3A-1500-5T-TJ-C-BIG BM 3A 5,000 1,500 BIG BM 204
T-3A-2000-5T-TJ-BIG BM 3A 5,000 2,000 BIG BM 207
T-4A-1500-8T-TJ-BIG BM 4A 8,000 1,500 BIG BM 198
T-4A-2000-8T-TJ-BIG BM 4A 8,000 2,000 BIG BM 240
T-4A-2000-8T-TJ-C-BIG BM 4A 8,000 2,000 BIG BM 271
T-4A-2200-8T-TJ-BIG BM 4A 8,000 2,200 BIG BM 241
T-4A-1500-12T-TJ-C-BIG BM 4A 12,000 1,500 BIG BM 243
T-4A-2500-12T-TJ-BIG BM 4A 12,000 2,500 BIG BM 360
T-4A-2500-12T-TJ-BM L150-180 4A 12,000 2,500 BM L150-180 446
