LANDYINDUS Hydraulic Power Silage Grab | Front Loader Tractor | Removable Tines

LANDYINDUS T-PSG Hydraulic Power Silage Grab | Front Loader Tractor | Removable Tines | Euro & SMS

The LANDYINDUS T-PSG Hydraulic Power Silage Grab is a high-performance front loader attachment engineered for efficient silage handling on farms of all sizes. Powered through a dedicated third hydraulic control circuit, this silage grab delivers powerful clamping force that cuts through dense silage with minimal operator effort. Available in 1,500mm (T-150PSG) and 1,800mm (T-180PSG) configurations with Euro and SMS bracket options, the T-PSG series significantly reduces labour time and improves overall farm productivity across large-scale livestock feeding operations and daily forage distribution.

Circular-Motion Tines — Clean Penetration & Firm Grip on Every Load

Built with precision-engineered tines that move in a circular motion, the T-PSG penetrates silage stacks cleanly and securely, ensuring a firm grip on every load. The optimised tine spacing is carefully calculated to minimise material loss during handling — keeping feed where it belongs and reducing waste on every cycle. Three tine zones work together: bottom tines for penetration, top tines for clamping, and side tines for lateral containment.

Removable Tines in Tapered Sleeves — Fast Field Maintenance & Replacement

All tines are fitted into tapered sleeves and are fully removable, making maintenance and replacement straightforward even in demanding field conditions. Individual tine replacement eliminates the need to remove or replace the full grab assembly — minimising downtime during busy feeding seasons and reducing the long-term cost of consumable components.

16 MPa / 60 LPM | SWL up to 467kg — Built for Daily Heavy-Duty Farm Use

With a safe working load of up to 467kg, operating pressure of 16 MPa, and hydraulic flow requirement of 60 LPM, the T-PSG is built to handle the rigours of daily farm use. The robust steel construction ensures long service life under continuous heavy-duty silage and forage handling conditions across extended working seasons.

Three Models — Euro & SMS | 1500mm & 1800mm

• T-150PSG-EURO — 1,500mm | SWL 394kg | Bottom φ36×880×8 | Top φ36×880×7 | Side φ36×810×2 | EURO | 253kg
• T-180PSG-EURO — 1,800mm | SWL 467kg | Bottom φ36×880×10 | Top φ36×880×9 | Side φ36×810×2 | EURO | 304kg
• T-180PSG-SMS-C — 1,800mm | SWL 467kg | Bottom φ36×880×10 | Top φ36×880×9 | Side φ36×810×2 | SMS | 286kg

Key Features

• Dedicated third hydraulic circuit — powerful clamping force through dense silage
• Circular-motion tines — clean penetration & secure grip on every load
• Optimised tine spacing — minimises material loss and feed waste per cycle
• Removable tines in tapered sleeves — fast field maintenance, individual replacement
• SWL up to 467kg | 16MPa / 60LPM — daily heavy-duty farm use
• 1,500mm & 1,800mm widths — Euro & SMS bracket options
• Robust steel construction — long service life across extended working seasons
• Compatible with a wide range of standard tractor front loaders

Technical Drawing:

Specifications
