LANDYINDUS Hydraulic Root Grapple Rake | 72" (1,830mm) | 1,590kg SWL | 490–1,270mm Opening | 900mm Replaceable Cast Teeth | Euro | Rocks, Logs & Brush | T-ERGR1830

LANDYINDUS T-ERGR1830 Hydraulic Root Grapple Rake | 72" (1,830mm) Working Width | 1,590kg SWL | 490–1,270mm Extra-Wide Opening | 900mm Replaceable Cast Bucket Teeth | Euro Coupler | Rocks, Logs, Brush & Stumps | 16 MPa | 60 LPM | 536kg

The LANDYINDUS T-ERGR1830 Hydraulic Root Grapple Rake is a heavy-duty loader attachment engineered for tackling the toughest land-clearing, debris removal, and material handling jobs on farms, construction sites, and forestry operations. Designed to pick up, push, and grip rocks, logs, brush, stumps, and other oddly shaped or hard-to-lift material, this extreme grapple rake gives operators the power and versatility to clear large areas quickly and efficiently.

490–1,270mm Extra-Wide Rake Opening — Wraps Around Oversized Root Masses, Large Rock Piles and Dense Brush Bundles

The extra-wide rake-style opening, ranging from 490mm to 1,270mm, is purpose-built for pushing and gripping large, bulky loads that standard grapples struggle to handle. This generous opening range allows the attachment to wrap securely around oversized root masses, large rock piles, and dense brush bundles, maintaining a firm grip throughout the entire lift and transport cycle. The 780mm total opening travel is the widest in the LANDYINDUS grapple range.

900mm Replaceable Cast Bucket Teeth — Swap Individual Worn Teeth, Not the Entire Attachment

Replaceable cast bucket teeth add long-term value by allowing worn teeth to be swapped out individually rather than replacing the entire attachment, significantly reducing maintenance costs and downtime over the life of the equipment. The 900mm tooth length and 12mm thickness provide deep penetration into compacted root masses, rocky soil, and dense brush piles, while the cast construction delivers superior impact resistance compared to fabricated alternatives.

1,590kg SWL | 72" (1,830mm) Working Width — Large-Area Land Clearing in Fewer Passes

With a safe working load of 1,590kg and a 72-inch (1,830mm) working width, the T-ERGR1830 covers large areas quickly, making light work of clearing overgrown land, storm debris, and construction site preparation. The wide working width matches the T-MF1830 manure fork and T-RP1830 rock picker — consistent 72-inch coverage across the LANDYINDUS heavy-duty attachment range.

Root Grapple Rake vs Timber Grab vs Silage Grab — Which Hydraulic Grapple for Your Task?

Applications

• Land reclamation — overgrown land, root mass removal, stump clearing
• Storm damage cleanup — fallen trees, branches, debris piles
• Construction site prep — rock clearing, brush removal, grading prep
• Farm maintenance — fence line clearing, rock picking, debris removal
• Forestry operations — slash clearing, log and brush handling

Key Features

• 490–1,270mm extra-wide opening — oversized root masses, rock piles, dense brush
• 900mm replaceable cast bucket teeth — individual replacement, not full attachment
• 1,590kg SWL | 72" (1,830mm) working width — large-area clearing in fewer passes
• Euro coupler — wide tractor and front loader compatibility, no adapters
• Rocks, logs, brush, stumps — single attachment for all land clearing materials
• 16 MPa | 60 LPM | 536kg | 1,830×1,361×969mm

Technical Drawing:

Specifications
