LANDYINDUS T-SPE Hydraulic Snow Blade | 28.5° Hydraulic Swing | Spring-Loaded Collision Protection | Adjustable Skids | 1.4–3.0m | 613mm Blade Height | Standard 4mm & Heavy-Duty 8mm Plate | Euro, SMS, Trima, ALO, Big BM, Zettlemeyer 602 | Front Loader | 16 MPa | 60 LPM
The LANDYINDUS T-SPE Hydraulic Snow Blade is a professional-grade front loader attachment engineered for efficient, precise, and operator-friendly snow clearing across a wide range of farm, commercial, and municipal applications. Featuring a 28.5° hydraulic swing angle that allows the operator to redirect snow discharge to either side from the cab, the T-SPE enables smooth, continuous clearing without stopping to manually reposition the blade. Available in eight blade widths from 1.4m to 3.0m, the T-SPE can be matched precisely to the scale of your clearing operation and the capacity of your front loader.
Spring-Loaded Collision Protection — Automatic Blade Release on Hidden Obstacle Impact, Protects Loader and Tractor
One of the standout features of the T-SPE is its spring-loaded trigger mechanism, which automatically releases the blade upon impact with hidden obstacles such as curbs, manhole covers, or frozen debris embedded in the snow. This collision protection system prevents sudden shock loads from transferring to the front loader and tractor, protecting both the attachment and the base machine from costly impact damage during high-speed clearing passes. This is a critical safety and cost-protection feature for municipal and commercial operators clearing at speed on roads and car parks.
28.5° Hydraulic Swing + Adjustable Skids — Cab-Controlled Direction, Precise Ground Clearance
The 28.5° hydraulic swing angle allows the operator to redirect snow discharge left or right from the cab without stopping. Adjustable skids allow the operator to set the blade’s ground clearance precisely, delivering controlled, consistent scraping performance across varying surface conditions — from smooth paved roads to uneven gravel tracks and farm yards.
Standard 4mm vs Heavy-Duty 8mm Main Plate — Choose by Loader Horsepower and Snow Conditions
| Feature | T-SPE Standard (4mm) | T-SPE Heavy-Duty (8mm) |
|---|---|---|
| Main plate thickness | 4mm | 8mm — double standard |
| Available widths | 1.4 / 1.6 / 1.8 / 2.0 / 2.2 / 2.4 / 2.8 / 3.0m | 2.0 / 2.2 / 2.4m |
| Best for | Standard agricultural and commercial use | High-HP loaders, heavy compacted snow & ice |
| Bending resistance | Standard | Superior — double plate thickness |
| Weight (2.0m) | 265kg | 295kg |
Broadest Bracket Compatibility in the Snow Blade Range — Euro, SMS, Trima, ALO, Big BM, Zettlemeyer 602
The T-SPE is available with an exceptionally broad range of bracket compatibility options, including Global Euro, Trima SMS, Big BM, ALO, and Zettlemeyer 602, with both weld-on and bolt-on mounting configurations available to suit different loader setups. This wide bracket compatibility means the T-SPE can be fitted to virtually any standard agricultural front loader without the need for custom adapters or fabrication work. Contact us to specify your bracket type when ordering.
T-SPE Front Loader Snow Blade vs T-SP 3-Point Snow Plow — Front Loader vs 3-Point Hitch
| Feature | T-SP / T-SP-NHY (3-Point) | T-SPE (This — Front Loader) |
|---|---|---|
| Mount | 3-point hitch — rear of tractor | Front loader — front of tractor |
| Visibility | Operator faces forward, blade behind | Operator faces blade — direct sightline |
| Collision protection | No | Spring-loaded trigger — auto release on impact |
| Adjustable skids | Optional wheels | Adjustable skids — precise ground clearance |
| Bracket options | Cat 1 / Cat 2 — 3-point | Euro, SMS, Trima, ALO, Big BM, Zettlemeyer |
| Width range | 1.5–3.0m | 1.4–3.0m |
| Plate options | 5mm only | 4mm standard & 8mm heavy-duty |
Standard Models — 1.4–3.0m (4mm Plate)
| Model | Width | Dimensions W×D×H (mm) | Blade Height (mm) | Plate (mm) | Weight (kg) |
|---|---|---|---|---|---|
| T-SPE1.4-SMS-C | 1,400mm | 1,400×936×672 | 613 | 4 | 244 |
| T-SPE1.6-SMS-C | 1,600mm | 1,600×936×672 | 613 | 4 | 251 |
| T-SPE1.8-SMS-C | 1,800mm | 1,800×936×672 | 613 | 4 | 258 |
| T-SPE2.0-SMS-C | 2,000mm | 2,000×936×672 | 613 | 4 | 265 |
| T-SPE2.2-SMS-C | 2,200mm | 2,200×936×672 | 613 | 4 | 272 |
| T-SPE2.4-SMS-C | 2,400mm | 2,400×936×672 | 613 | 4 | 279 |
| T-SPE2.8-SMS-C | 2,800mm | 2,800×936×672 | 613 | 4 | 294 |
| T-SPE3.0-SMS-C | 3,000mm | 3,000×936×672 | 613 | 4 | 300 |
Heavy-Duty Models — 2.0–2.4m (8mm Plate)
| Model | Width | Dimensions W×D×H (mm) | Blade Height (mm) | Plate (mm) | Weight (kg) |
|---|---|---|---|---|---|
| T-SPE2.0-HD-SMS-C | 2,000mm | 2,000×940×675 | 613 | 8 | 295 |
| T-SPE2.2-HD-SMS-C | 2,200mm | 2,200×940×675 | 613 | 8 | 315 |
| T-SPE2.4-HD-SMS-C | 2,400mm | 2,400×940×675 | 613 | 8 | 328 |
Key Features
- 28.5° hydraulic swing — cab-controlled snow discharge direction, continuous clearing
- Spring-loaded collision protection — auto blade release on hidden obstacle impact
- Adjustable skids — precise ground clearance, paved roads to gravel tracks
- Standard 4mm (1.4–3.0m) & Heavy-Duty 8mm (2.0–2.4m) plate options
- 613mm blade height | hardened steel cutting edge — full blade width
- Euro, SMS, Trima, ALO, Big BM, Zettlemeyer 602 — weld-on & bolt-on
- Red powder coat finish | 16 MPa | 60 LPM | 244–328kg
Technical Drawing:
