LANDYINDUS Hydraulic Tree Shear for Excavator | Dual Cylinder Replaceable Blade | 25cm Cut | 2–6 Ton

LANDYINDUS E-TS Series Hydraulic Tree Shear for Excavator | Dual Cylinder | Replaceable Blade | 25cm Cut | 2–6 Ton

The LANDYINDUS E-TS Series Hydraulic Tree Shear is the purpose-built excavator tool for land-clearing contractors, forestry operators, and agricultural developers who need to fell, cut, and clear trees and brush quickly, safely, and efficiently from the cab of their machine. Powered by two high-force hydraulic cylinders working in tandem, the E-TS series delivers the fast, powerful cutting action needed to fell timber up to 25 cm in diameter — covering the vast majority of trees encountered in land-clearing, right-of-way maintenance, orchard removal, and light forestry applications.

Dual-Cylinder Drive — Greater Closing Force, Faster Cycle Times

With two cylinders driving the cutting jaw simultaneously, the E-TS generates significantly greater closing force and faster cycle times than single-cylinder alternatives — cutting through hardwood and softwood species up to 25 cm thick in a single, clean motion without stalling or requiring multiple passes. Faster cuts mean more trees cleared per hour, lower fuel consumption per cycle, and reduced operator fatigue across a full working shift.

Replaceable High Wear-Resistant Steel Blade — Field Serviceable

The specially designed replaceable cutting blade is manufactured from high wear-resistant steel to maintain a sharp, effective cutting edge through thousands of cutting cycles. When the blade reaches the end of its service life, it can be replaced quickly and cost-effectively in the field — without returning the attachment for workshop servicing or investing in an entirely new shear unit. This replaceability significantly reduces long-term cost of ownership and keeps the attachment performing at full efficiency throughout its operational life.

Two Models — 2T to 6T Excavator Classes

• ME-TS180 — 803×632×1132mm | Opening 170–660mm | S30/S40 | 190kg | Suits 2–3.5T | Ideal for brush clearing, sapling removal & light timber felling on compact machines
• E-TS250 — 833×632×1132mm | Opening 240–890mm | S45/S50/S60 | 350kg | Suits 4–6T | Additional reach and cutting force for larger-diameter timber and heavier land-clearing workloads

16 MPa / 60 LPM — S30, S40, S45, S50 & S60 Bracket Compatibility

Both models operate at 16 MPa with a hydraulic flow requirement of 60 LPM, integrating seamlessly with standard excavator auxiliary hydraulic circuits. Compatible with S30, S40, S45, S50, and S60 quick-coupler standards — no custom adapters required.

Key Features

• Dual hydraulic cylinders — greater closing force & faster cycle times than single-cylinder shears
• Cuts timber up to 25cm diameter in a single clean motion
• Replaceable high wear-resistant steel blade — field serviceable, no workshop required
• Two models: ME-TS180 (2–3.5T) & E-TS250 (4–6T)
• Opening range 170–660mm (ME-TS180) and 240–890mm (E-TS250)
• 16 MPa / 60 LPM — standard excavator hydraulic circuit compatible
• S30, S40, S45, S50, S60 bracket options — no custom adapters required
• High-strength alloy steel frame — absorbs shock and stress of continuous cutting

Technical Drawing:

Specifications
