LANDYINDUS Landscape Power Rake | 72" (1,800mm) | 485mm Disc | 6mm Tines | Water-Fill Roller | Cat 2 3-Point Hitch | Seedbed Prep & Leveling | T-PW1830

LANDYINDUS T-PW1830 Landscape Power Rake | 72" (1,800mm) Working Width | 485mm Disc System | 6mm Rake Tines | Water-Fill Compaction Roller | Cat 2 3-Point Hitch | Seedbed Preparation, Soil Leveling & Lawn Renovation

The LANDYINDUS T-PW1830 Landscape Power Rake is a heavy-duty 3-point hitch attachment designed for Cat 2 tractors, delivering professional-grade soil grading, leveling, and seedbed preparation across a 1,800mm (72") working width. Built around a 485mm diameter disc system with 6mm rake tines, it breaks through compacted soil, levels uneven ground, and prepares a clean, workable seedbed in a single pass — reducing the time and labor that traditional tillage equipment demands.

485mm Disc System | 6mm Rake Tines — Penetrates Compacted Soil, Consistent Spacing Across Full Width

The 485mm diameter disc system with 6mm rake tines penetrates hard, compacted ground without bending or losing spacing — keeping performance consistent across the full 1,800mm working width throughout the working season. The robust tine construction is the key durability advantage over lighter-gauge power rakes that lose tine spacing under sustained use on hard ground.

Water-Fill Compaction Roller — Adjustable Weight for Seedbed Firming After Raking

The roller features a steel fill cap located on its side, allowing you to fill the drum with water to increase compaction weight as required. This adjustable ballast capability allows the operator to tune the roller pressure to match the soil type and seedbed specification — lighter for sandy soils, heavier for clay-based seedbeds that require firmer consolidation before seeding. The roller firms the prepared seedbed immediately after the tines pass, completing soil preparation and light compaction in a single attachment pass.

Single-Pass Operation — Break, Level, and Firm in One Pass

The T-PW1830 combines three operations in a single pass:

• Break — 485mm disc tines penetrate and loosen compacted soil
• Level — 1,800mm working width grades and evens the surface
• Firm — water-fill roller consolidates the seedbed immediately behind the tines

This single-pass capability reduces the number of tractor passes required for seedbed preparation compared to running separate tillage, grading, and rolling operations.

Cat 2 3-Point Hitch | 107kg — Effective Ground Penetration Without Overloading Rear Linkage

Compatible with standard Cat 2 three-point hitch tractors, the T-PW1830 mounts quickly and requires no special adapters for most utility and mid-frame tractors. At 107kg, it delivers the weight needed for effective ground penetration without overloading the tractor’s rear linkage.

T-PW1830 vs T-3P-RGB — Power Rake vs Grading Blade

Key Features

• 485mm disc system | 6mm rake tines — compacted soil penetration, consistent spacing
• Water-fill compaction roller — adjustable ballast, seedbed firming after raking
• Single-pass: break + level + firm — reduces total tractor passes
• 1,800mm (72") working width — maximum coverage per pass
• Cat 2 3-point hitch — utility and mid-frame tractor compatibility
• 107kg — effective ground penetration, rear linkage compatible
• Seedbed prep, lawn renovation, driveway grading, field preparation

Technical Drawing:

Specifications
