LANDYINDUS Pallet Forks Frame | 2,000kg SWL | Class 2A | 49" (1,240mm) | Tool-Free Hookup | Adjustable Latch-Lock Tines | Load Guard | Euro | T-PF2A

LANDYINDUS T-PF2A Pallet Forks Frame | 2,000kg SWL | Euro Class 2A | 49" (1,240mm) | Tool-Free Hookup | Adjustable Latch-Lock Tines | Heavy-Duty Load Guard | Euro Hitch

The LANDYINDUS T-PF2A Pallet Forks Frame is engineered for operators who need a reliable, heavy-duty lifting solution that connects quickly and works hard. Designed to Euro Class 2A standards with a safe working load of 2,000kg, this frame is well-suited for farm, construction, and warehouse applications where consistent performance under pressure is non-negotiable.

Tool-Free Hookup | No-Hinge Fork Tine Design — Fast Attach and Detach During Busy Work Cycles

One of the standout features of this pallet forks frame is its tool-free hookup system. The no-hinge fork tine design allows you to attach and detach the unit with minimal effort, saving time during busy work cycles. This is a significant operational advantage over traditional hinged fork designs that require tools or manual pin removal for tine changes.

Adjustable Latch-Lock Tines — Slide and Lock for Any Pallet Width, No Compromise on Stability

The adjustable latch-locked fork tines slide and lock securely into position, giving you the flexibility to handle a wide range of pallet sizes without compromising stability or safety. The latch-lock mechanism ensures the tines cannot shift under load — a critical safety feature when handling heavy or uneven cargo at height.

Three Fork Tine Cross-Section Options — Match Forks to Your Specific Load Requirements

The frame accommodates 1.2-meter fork tines in three cross-section options:

• 100×35mm — lighter loads, standard agricultural pallets
• 100×40mm — medium-duty, increased tine rigidity
• 120×40mm — heavy-duty, maximum tine strength for demanding loads

Specify your required cross-section at the time of order.

Heavy-Duty Load Guard — Operator and Load Protection During Lifting

A heavy-duty load guard is integrated into the frame to protect both the operator and the load during lifting, adding an extra layer of confidence when working with bulky or uneven cargo. The load guard prevents material from falling back toward the cab during transport — a critical safety feature on a 2,000kg-rated frame.

T-PF2A vs CTJ vs T-Series vs T-SFF — Euro Class 2A Fork Frame Comparison

Custom Options Available — Frame Size, Fork Tine Dimension, Bracket Configuration

If you require a different frame size, fork tine dimension, or bracket configuration, custom options are available on request. Contact us to discuss your specific application.

Key Features

• 2,000kg SWL | Euro Class 2A | 49" (1,240mm)
• Tool-free hookup — no-hinge tine design, fast attach/detach
• Adjustable latch-lock tines — any pallet width, secure under load
• Three tine cross-sections: 100×35 / 100×40 / 120×40mm — specify at order
• Integrated heavy-duty load guard — operator and load protection
• Euro hitch | 103kg | 1,240×179×800mm
• Custom frame size, tine dimension and bracket available on request

Technical Drawing:

Specifications
