LANDYINDUS Round Bale Spear | 1,000kg SWL | φ45×1,250mm + Conical Casing | φ36×690mm Stabilizer | SMS Quick Attach | Skid Steer | T-RBS12

LANDYINDUS T-RBS12 Round Bale Spear | 1,000kg SWL | φ45×1,250mm Main Spear with Premium Conical Casing | φ36×690mm Stabilizer Spear | SMS Quick Attach | Skid Steer Loader | 69kg

The LANDYINDUS T-RBS12 Round Bale Spear is a heavy-duty skid steer attachment built for the efficient transport and stacking of unwrapped round bales, designed to connect directly to SMS hitch skid steer loaders without additional adapters or mounting hardware. With a safe working load of 1,000kg, this bale spear provides the lifting capacity needed to handle large round bales confidently across farm, ranch, and feedlot environments.

Premium Conical Casing — Protects Main Spear Base from Lateral Stress, Extends Working Life vs Unprotected Alternatives

The spear is housed in a premium conical casing that protects the base of the main spear from the lateral stress and impact forces generated during repeated bale penetration and lifting cycles. This conical sleeve design significantly extends the working life of the spear compared to unprotected alternatives, reducing the risk of stress fractures at the base and maintaining structural integrity under continuous heavy use. The base of the main spear is the highest-stress point on any bale spear — the conical casing is the engineering solution that addresses this directly.

φ45×1,250mm Main Spear — 49" Full Penetration to Center and Secure Large Round Bales

The main spear measures φ45mm in diameter and 1,250mm (approximately 49 inches) in length, giving the operator the penetration depth required to fully engage and center large round bales during the pickup. The φ45mm diameter matches the standard industrial bale spear specification.

φ36×690mm Stabilizer Spear — Prevents Bale Rotation at Loader Height on Uneven Ground

A stabilizer spear measuring φ36mm in diameter and 690mm in length is positioned alongside the main spear to prevent bale rotation and lateral movement during transport. When carrying a round bale at loader height across uneven ground, bale stability is critical — the stabilizer spear maintains consistent contact with the bale surface and keeps the load centered and controlled throughout the carry cycle. This dual-spear configuration makes the attachment particularly effective for stacking bales in storage areas where precise placement is required.

SMS Quick Attach — Fast, Tool-Free Install on Most Modern Skid Steer Machines

Compatible with SMS hitch skid steer loaders, the T-RBS12 installs quickly and securely using the standard SMS quick-attach system found on most modern skid steer machines. No additional adapters or mounting hardware required.

Bale Handling Series — Skid Steer vs Tractor, SMS vs 3-Point vs John Deere

Key Features

• Premium conical casing — protects main spear base, extends working life vs unprotected
• φ45×1,250mm main spear — 49" full penetration, large round bale centering
• φ36×690mm stabilizer spear — anti-rotation, stable at loader height on uneven ground
• 1,000kg SWL | SMS quick attach — no adapters, most modern skid steers
• 69kg | 1,358×1,140×466mm — compact, barn and storage maneuverable
• Unwrapped round bales — field to barn, stacking, trailer loading

Technical Drawing:

Specifications
