LANDYINDUS S-HBG Skid Steer Hydraulic Round Hay Bale Grab Grapple | 1300kg Dual Bale Quick Attach

LANDYINDUS S-HBG Skid Steer Hydraulic Round Hay Bale Grab Grapple | 1300kg Dual Bale Quick Attach

Move two bales at once. Protect every wrap. The LANDYINDUS S-HBG Skid Steer Hydraulic Round Hay Bale Grab is a heavy-duty quick attach grapple attachment designed for fast, efficient movement and stacking of round hay bales on farms, ranches, and large-scale hay contracting operations. Rated to a 1300kg safe working load and compatible with round bales from 1220mm to 1830mm in diameter (4’ to 6’), the S-HBG handles the full range of standard round bales without any adjustment or reconfiguration between jobs.

Full-Contact Hydraulic Grip — 950mm to 2200mm Opening Range

The hydraulic arms open from 950mm to a maximum of 2200mm, giving you the reach to wrap around even the largest round bales with a secure, full-contact grip that keeps the bale stable throughout every lift, carry, and stack cycle. The system operates at 16 MPa with a hydraulic flow requirement of 60 LPM, delivering smooth and responsive arm movement even under maximum load.

Cradle Design — Protects Silage Wrap Integrity

Unlike bale spears that penetrate the bale and risk wrap damage, the S-HBG's grab design cradles the bale from the outside — making it the preferred choice for handling wrapped silage bales where preserving wrap integrity is critical to preventing feed spoilage. Every bale arrives at the stack exactly as it left the field.

Dual-Bale Stacking — Cut Handling Time in Half

One of the standout productivity features of the S-HBG is its dual-bale stacking capability, allowing you to pick up and move two round bales simultaneously in a single pass. For high-volume hay operations, large livestock farms, or hay contractors moving hundreds of bales per day, handling two bales at once cuts your total handling time and machine hours in half — directly reducing fuel costs and operator fatigue over the course of a season.

Engineered for Commercial-Scale Daily Use

At 1440mm wide × 2037mm tall × 900mm deep and weighing 359kg, the S-HBG is engineered for the structural demands of daily commercial bale handling. The heavy-duty frame and hydraulic system are built to perform reliably through the repetitive stress of high-volume operations season after season.

Key Features

• 1300kg safe working load — handles the heaviest round bales
• Compatible with 4’ to 6’ round bales (1220mm–1830mm diameter)
• Hydraulic opening range: 950mm to 2200mm for full-contact bale grip
• Cradle grab design — protects silage wrap integrity, no puncture risk
• Dual-bale stacking capability — move two bales per pass
• 16 MPa operating pressure / 60 LPM hydraulic flow
• Universal quick tach compatible — no adapters or modifications required

Technical Drawing:

Specifications
