LANDYINDUS S-PB Skid Steer Hydraulic Pickup Broom | 47" Sweep, Collect & Dump Collection Hopper Quick Attach

LANDYINDUS S-PB Skid Steer Hydraulic Pickup Broom | 47" Sweep, Collect & Dump Collection Hopper Quick Attach

Sweep. Collect. Dump. From the cab. The LANDYINDUS S-PB1200 Skid Steer Hydraulic Pickup Broom is a heavy-duty quick attach sweeping attachment that combines sweeping, collecting, and dumping into a single integrated operation — eliminating the need for a separate collection vehicle or manual debris removal that conventional rotary brooms require. With a 47" (1200mm) sweeping width and a built-in 0.39m³ collection hopper, the S-PB1200 sweeps debris directly into the onboard hopper as it works, allowing continuous sweeping of large surface areas before stopping to dump collected material in a designated location.

Sweep-to-Hopper Transfer — No Redistribution, No Manual Cleanup

The hydraulically driven brush drum features a 550mm diameter drum with 26 brush elements, delivering consistent rotary sweeping action that efficiently picks up dirt, gravel, asphalt millings, pothole patch material, sand, and loose debris from paved roads, parking lots, construction sites, and municipal surfaces. The brush-to-hopper transfer mechanism ensures swept material is captured and retained in the hopper rather than redistributed across the surface — a critical advantage on road maintenance and pothole repair jobs where clean, debris-free surfaces are required before patching or resurfacing work begins.

Hydraulic Cab-Controlled Dump — Empty the Hopper Without Dismounting

The hydraulic dumping function allows the operator to empty the 0.39m³ hopper directly from the cab without dismounting — depositing collected material into a truck bed, waste container, or designated dump area with precise hydraulic control. This cab-controlled dump cycle eliminates the manual labor of emptying a collection bin by hand, keeping the operator productive and on the machine throughout the entire sweep-collect-dump cycle. A significant time and labor saving on high-volume municipal sweeping routes, road maintenance contracts, and large-scale construction site cleanup operations.

Built for Commercial & Municipal Daily Use

The system operates at 16 MPa with a hydraulic flow requirement of 60 LPM. At 1640mm × 1302mm × 707mm and weighing 500kg, the S-PB1200 is engineered for the structural demands of daily commercial and municipal sweeping work — built to perform reliably through high-volume, repetitive sweep-collect-dump cycles season after season.

Key Features

• 3-in-1 operation: sweep, collect, and hydraulic dump in a single attachment
• 47" (1200mm) sweeping width with 0.39m³ onboard collection hopper
• 550mm brush drum with 26 brush elements for consistent debris pickup
• Brush-to-hopper transfer — no debris redistribution across the surface
• Cab-controlled hydraulic dump — no dismounting required to empty hopper
• Picks up dirt, gravel, asphalt millings, sand, and loose debris
• 16 MPa / 60 LPM hydraulic system
• Universal quick tach compatible — no adapters or modifications required

Technical Drawing:

Specifications
