LANDYINDUS S-SBH Skid Steer Quick Attach Bale Lifter & Handler | 1000kg Roller Tube Silage Wrap Protection

LANDYINDUS S-SBH Skid Steer Quick Attach Bale Lifter & Handler | 1000kg Roller Tube Silage Wrap Protection

No punctures. No tears. No spoilage. The LANDYINDUS S-SBH Skid Steer Bale Lifter Handler is a heavy-duty quick attach attachment purpose-built for handling wrapped silage bales, round hay bales, and plastic-wrapped bales without causing any damage to the protective wrapping. Unlike bale spears that puncture through the wrap or hydraulic grabs that apply concentrated clamping pressure, the S-SBH uses a roller tube design that distributes lifting pressure evenly across the full surface of the bale — keeping the plastic wrap completely intact throughout every lift, carry, and stack operation.

Roller Tube Design — Even Pressure Distribution, Zero Wrap Damage

The generous length and diameter of the steel roller tubes are engineered to maximize the contact surface area between the lifter and the bale, spreading the load across a wide area rather than concentrating stress at a single point. This even pressure distribution is what makes the S-SBH the safest bale handling option for wrapped silage bales destined for winter feed storage — where even a small puncture or tear in the wrap can lead to spoilage and significant feed loss over time. If you've been losing wrapped bales to puncture damage from conventional spears or grabs, the S-SBH eliminates that problem entirely.

Adjustable Opening Range — 778mm to 1152mm

The lifter arms adjust from 778mm to 1152mm, accommodating a wide variety of round bale diameters in a single attachment without any manual reconfiguration between jobs. One attachment, every bale size on your operation.

1000kg Safe Working Load — Handles the Heaviest Round Bales

Rated to a 1000kg safe working load, the S-SBH handles the heaviest standard round bales with confidence. At 1320mm wide × 1394mm tall × 698mm deep and weighing 105kg, the frame is compact and well-balanced on your skid steer's quick attach plate — delivering stable, controlled lifts in tight barn spaces and yard environments where larger attachments can't maneuver.

Universal Quick Tach — No Adapters Required

Compatible with standard skid steer quick tach systems, the S-SBH mounts directly to your machine without adapters or modifications — ready to work from the moment it's on the plate.

Key Features

• Roller tube design — distributes lifting pressure evenly, zero wrap puncture risk
• Wrap-safe handling for silage bales, round hay bales, and plastic-wrapped bales
• Adjustable opening range: 778mm to 1152mm — fits a wide range of round bale diameters
• 1000kg safe working load
• Compact frame (1320 × 1394 × 698mm) for stable lifts in tight barn and yard spaces
• Universal quick tach compatible — no adapters or modifications required

Technical Drawing:

Specifications
