LANDYINDUS F-FMJ3T Telescoping Forklift Jib Boom | 3T SWL | 3.5m Max Reach | Skid Steer Compatible | Double Fork Mobile Crane
The LANDYINDUS F-FMJ3T Telescoping Forklift Jib Boom is a heavy-duty mobile crane attachment that instantly converts your forklift or skid steer into a fully functional overhead lifting machine — no dedicated crane equipment required. Rated at a 3,000 kg (3T) safe working load, this attachment delivers the reach, height, and load capacity needed to lift, transport, and precisely place heavy payloads well beyond the capability of standard pallet forks.
Telescopic Extension — 2.46m to 3.5m Reach
The full telescoping range extends from a retracted base length of 2,465mm out to a maximum reach of 3,505mm, providing over 1 metre of adjustable extension. This enables operators to match the boom extension precisely to the lift geometry — whether clearing a low barrier, reaching into a deep container, loading onto a flatbed trailer, or placing materials at height in a racking system.
This flexibility makes the F-FMJ3T one of the most operationally versatile forklift jib boom attachments available in the 3-tonne capacity class, eliminating the need for multiple fixed-length jib attachments across a single site.
Double Fork Design & Skid Steer Compatibility
Designed with a double-fork mounting system, the F-FMJ3T fits directly onto most standard pallet forks and installs in seconds. There are no tools, no welding, and no permanent modifications required. The double-fork design distributes load stress evenly across both fork tines, maximizing structural stability during overhead lifts and ensuring safe, controlled operation even at maximum rated capacity.
Because it mounts directly to pallet forks, this highly versatile jib boom is fully compatible with both standard forklifts and skid steers equipped with fork attachments, making it a highly cost-effective cross-fleet asset.
Precision Load Balancing — 2 Hooks Included
The jib boom is equipped with 2 heavy-duty hooks and features multiple hook positions spanning from 737mm to 3,505mm from the base of the boom (spaced 229mm apart). This adjustable hook positioning system gives operators precise control over the load's centre of mass. Fine-tuning the load balance for irregularly shaped or off-centre payloads significantly reduces the risk of load swing, tip, or drop during lifting and transport operations.
Applications
- Construction Sites — lifting steel, timber, and equipment using a rough-terrain skid steer
- Warehousing & Manufacturing — overhead lifting of heavy machinery and dies
- Equipment Yards — a cross-fleet mobile crane alternative for mixed machinery
- Logistics — loading and unloading flatbed trailers and deep shipping containers
Key Features
- 3.0 Tonne (3,000kg) Safe Working Load
- Telescopic boom extends from 2,465mm to 3,505mm
- Double fork slip-on design — installs in seconds
- Compatible with both forklifts and skid steers
- Includes 2 hooks with multiple adjustment points (spaced 229mm apart)
- Heavy-duty 280kg construction for extreme durability
Specifications
| Model | SWL | Dimensions L×W×H (mm) | Fork Pocket (mm) | Pocket Centres (mm) | Weight (kg) |
|---|---|---|---|---|---|
| F-FMJ3T | 3T | 2,465×520×527 | 165×85 | 330 | 280 |
Technical Drawing
1. Leverage & Load De-rating: A 3.5m reach creates massive leverage. The 3T SWL rating applies ONLY when the jib is fully retracted and the hook is at the innermost position. As the jib extends outward, the lifting capacity drops dramatically. You MUST consult the load chart on the attachment and cross-reference it with your host machine's de-rated capacity chart before lifting.
2. Skid Steer Stability: When used on a skid steer, be extremely cautious of the machine's tipping load. Skid steers have a much shorter wheelbase than counterbalance forklifts, making them more susceptible to forward tipping when a load is extended far in front of the machine.
3. Pocket Size Verification: Verify your forklift or skid steer tines will fit within the generous 165×85mm pockets and match the 330mm pocket centres.
