LANDYINDUS Universal Bucket Tooth Bar No-Drill Heavy Duty Digging Teeth Bar for Loader Tractor Excavator 48 to 72 Inch G-BTB Series
Couldn't load pickup availability
Got questions?
Feel free to get in touch
Ask an expert!
Product Overview
Struggling to penetrate hard-packed clay, shale, and tree roots with a dull, flat loader bucket cutting edge? The LANDYINDUS G-BTB Series Universal No-Drill Bucket Tooth Bar converts smooth bucket lips into aggressive ground-breaking rippers with 16mm thick steel construction.
The LANDYINDUS G-BTB Series universal bucket tooth bar is purpose-engineered to slide and clamp directly over the cutting edge of standard skid steer, compact tractor, wheel loader, and mini-excavator buckets. Designed with an aggressive curved tooth geometry and a heavy 16mm main spine plate, it dramatically increases ground penetration force while eliminating the expense, downtime, and permanent damage of drilling or welding teeth onto your bucket.
Core Selling Points
- 100% No-Drill & No-Weld Installation: High-tensile reinforced bolts and heavy-duty rivets clamp securely over the cutting edge in minutes without drilling holes or altering the host bucket.
- 3 Standard Widths (48", 60" & 72"): Available in 48" (5 teeth / 33kg), 60" (6 teeth / 39kg), and 72" (7 teeth / 46kg) formats to match industry-standard commercial bucket widths.
- Aggressive Curved Penetration Teeth: Precision-angled curved teeth concentrate hydraulic breakout pressure to shatter hardpan, packed clay, caliche, and frozen soil with lower fuel consumption.
- Heavy-Gauge 16mm Solid Spine Plate: Massive 16mm thick structural steel backplate withstands repeated tooth impact and prying stresses without bending or root cracking.
Specifications
| Type | Bucket Width / in (mm) | Overall Dimension (W×D×H) / mm | Main Plate Thickness / mm | Teeth Qty. | Teeth Spacing / mm | Weight / kg |
|---|---|---|---|---|---|---|
| G-BTB48IN-5 | 48" (1200mm) | 1200×399×137 | 16 | 5 | 286 | 33 |
| G-BTB60IN-6 | 60" (1510mm) | 1510×399×137 | 16 | 6 | 288 | 39 |
| G-BTB72IN-7 | 72" (1825mm) | 1825×399×137 | 16 | 7 | 292 | 46 |
Technical Drawing
⚠️ Safety & Compatibility Warnings
- Pre-Operation Bolt Torque Check: Securely tighten all reinforced clamping bolts onto the bucket cutting edge prior to work. Re-torque bolts after the initial 30 minutes of heavy digging.
- Bucket Inside Width Compatibility: Measure inside bucket width accurately before ordering (1200mm for 48", 1510mm for 60", 1825mm for 72") to ensure a snug, non-binding fit.
- Underground Utility Locating: Always call local utility marking services before aggressive subsurface digging to prevent striking buried power, gas, or communication lines.
- Hydraulic Prying Thresholds: Designed for soil breakout, trenching, and gravel loosening. Avoid extreme lateral twisting or trying to lever immovable bedrock beyond machine breakout limits.
